SUSPENSION

ALUMINUM HEX SUSPENSION TUBES SWEDGED STEEL SUSPENSION TUBES
Used in steering and Swedged, D.O.M. steel tubes are black anodized. The 3/4"
suspension systems, O.D. tubes are .065" wall, 7/8" O.D. tubes are
hex tubes are easy to .083" wall and 1" O.D. tubes are
install and easy to adjust. Available in 7/8" hex with 5/8" threads tapped RH .095" wall.
and LH, and 1-1/8" hex with 3/4" threads tapped RH and LH, tubes are black 1/2" Thread 5/8" Thread 3/4" Thread
anodized for appearance and corrosion resistance. 6061-T6 material. Length 3/4" O.D. 7/8" O.D. 1" O.D.
5/8" 3/4" 5/8" 3/4" 4" ALL57052 ALL57152 –
Length Thread Thread Length Thread Thread 4-1/2" – ALL57153 –
3" - ALL56703 21" ALL56621 ALL56721 5" ALL57054 ALL57154 ALL57254
4" - ALL56704 22" ALL56622 ALL56722 5-1/2" – ALL57155 –
5" - ALL56705 23" – ALL56723 6" ALL57056 ALL57156 ALL57256
6" - ALL56706 24" – ALL56724 6-1/2" – ALL57157 –
7" ALL56607 ALL56707 25" – ALL56725 7" ALL57058 ALL57158 ALL57258
8" ALL56608 ALL56708 26" – ALL56726 7-1/2" – ALL57159 –
9" ALL56609 ALL56709 27" – ALL56727 8" ALL57060 ALL57160 ALL57260
10" ALL56610 ALL56710 28" – ALL56728 8-1/2" – ALL57161 –
11" ALL56611 ALL56711 29" – ALL56729 9" ALL57062 ALL57162 ALL57262
12" ALL56612 ALL56712 30" – ALL56730 10" ALL57064 ALL57164 ALL57264
13" ALL56613 ALL56713 32" – ALL56732 11" ALL57066 ALL57166 ALL57266
14" ALL56614 ALL56714 34" – ALL56734 12" ALL57068 ALL57168 ALL57268
15" ALL56615 ALL56715 36" – ALL56736 12-1/2" – ALL57169 –
16" ALL56616 ALL56716 38" – ALL56738 13" ALL57070 ALL57170 ALL57270
17" ALL56617 ALL56717 40" – ALL56740 13-1/2" – ALL57171 –
18" ALL56618 ALL56718 42" – ALL56742 14" ALL57072 ALL57172 ALL57272
19" ALL56619 ALL56719 44" – ALL56744 14-1/2" – ALL57173 –
20" ALL56620 ALL56720 15" ALL57074 ALL57174 ALL57274
16" ALL57076 ALL57176 ALL57276
UNTHREADED 72" HEX SUSPENSION 17" ALL57078 ALL57178 ALL57278
TUBES 18" ALL57080 ALL57180 ALL57280
ALL57082
ALL57182
19"
ALL57282
Part No. Description 20" ALL57084 ALL57184 ALL57284
ALL56672 72" x 7/8" Hex For 5/8" Rod Ends 21" ALL57086 – ALL57286
ALL56772 72" x 1-1/8" Hex For 3/4" Rod Ends 22" ALL57088 – ALL57288
23" ALL57090 – ALL57290
ALUMINUM 24" ALL57092 – ALL57292
SUSPENSION TUBES 25" ALL57094 – ALL57294
Swaged 1-1/8" O.D. tubes are 26" ALL57096 – –
built from .156" wall tubing 27" ALL57098 – –
and have 5/8" RH and LH 28" ALL57099 – –
threads.
5/8" Thread 5/8" Thread THREADED
Length Black Anodized Polished Aluminum TUBING ENDS
10" ALL56806-10 ALL56807-10
11" ALL56806-11 ALL56807-11 Chrome moly 4130 steel tubing ends are
12" ALL56806-12 ALL56807-12 ideal for building custom length suspension tubes.
12-1/2" ALL56806-125 ALL56807-125 Available in RH and LH threads.
13" ALL56806-13 ALL56807-13 Tube End Insert
13-1/2" ALL56806-135 ALL56807-135 Thread Size Tubing Size O.D. RH Part No. LH Part No.
14" ALL56806-14 ALL56807-14 10-32 3/8" x .058" .259" ALL22500 –
14-1/2" ALL56806-145 ALL56807-145 5/16"-24 1/2" x .058" .384" ALL22504 –
15" ALL56806-15 ALL56807-15 3/8"-24 5/8" x. .058" .509" ALL22508 ALL22509
16" ALL56806-16 ALL56807-16 3/8"-24 3/4" x .058" .634" ALL22512 ALL22513
17" ALL56806-17 ALL56807-17 1/2"-20 7/8" x .058" .759" ALL22518 ALL22519
18" ALL56806-18 ALL56807-18 1/2"-20 1" x .058" .884" ALL22522 ALL22523
18-1/2" ALL56806-185 ALL56807-185 1/2"-20 1" x .065" .870" ALL22526 ALL22527
19" ALL56806-19 ALL56807-19 1/2"-20 1-1/8" x .058" 1.00" ALL22530 ALL22531
19-1/2" ALL56806-195 ALL56807-195 5/8"-18 1" x .058" .884" ALL22534 ALL22535
20" ALL56806-20 ALL56807-20 5/8"-18 1" x .095" .810" ALL22538 ALL22539
20-1/2" ALL56806-205 ALL56807-205 5/8"-18 1-1/4" x .095" 1.060" ALL22542 ALL22543*
21" ALL56806-21 ALL56807-21 5/8"-18 1-1/4" x .120" 1.010" ALL22546 ALL22547*
21-1/2" ALL56806-215 ALL56807-215 3/4"-16 1-1/4" x .065" 1.120" ALL22548 ALL22549*
22" ALL56806-22 ALL56807-22 3/4"-16 1-1/4" x .095" 1.060" ALL22550 ALL22551*
22-1/2" ALL56806-225 ALL56807-225 3/4"-16 1-1/4" x .120" 1.010" ALL22554 ALL22555*
23" ALL56806-23 ALL56807-23 3/4"-16 1-3/8" x .095" 1.185" ALL22558 ALL22559*
23-1/2" ALL56806-235 ALL56807-235 * Tube end has built-in hex for adjusting.
24" ALL56806-24 ALL56807-24
24-1/2" ALL56806-245 ALL56807-245
