SUSPENSION

STEEL RADIUSED CLIMBING STYLE REMOTE ADJUSTABLE
FRAME MOUNT PANHARD BAR BRACKETS PANHARD BAR MOUNTS
Steel climbing style Easily adjusted on frame side of
adjuster mounts to chassis Panhard bar, mount has a threaded
square tubing and permits shaft and fastens to 1-3/4" diameter
Panhard/J-bar adjustment tubing. Standard mount kit has 2" of
without removing or re- adjustment, drop mount kit has 5"
aligning spacers or tabs found of adjustment. Each turn of the shaft
on other mounts. Radiused moves mount .100". Extension rod may
slot eliminates the need to be mounted in rear window or decking
re-square the rear end after for quick, easy adjustments from outside
adjustments. ALL60237 ALL60239 of the car. Mounting hardware and a 3/4" Panhard bar bolt
Part No. Description are included.
ALL60236 For 1-1/2" Tubing, Center Mounting Part No. Description
ALL60238 For 1-1/2" Tubing, Inside and Outside Mounting ALL60270 Standard Mount Kit
ALL60237 For 2" Tubing, Center Mounting ALL60273 Drop Mount Kit
ALL60239 For 2" Tubing, Inside and Outside Mounting Replacement Components
Extension Rod With Bushing
ALL60272
ALUMINUM RADIUSED For ALL60270/ALL60273
CLIMBING STYLE FRAME MOUNT ALL60274 Flange Bearing ALL60270 ALL60273
PANHARD BAR BRACKETS
Easily adjust your Panhard bar with only one ALUMINUM PANHARD BAR CLEVIS
wrench! Climbing style adjuster allows any amount Gold anodized aluminum clevis clamps around a
of adjustment without having to remove or re-align chassis tube and connects to the 3/4" rod end on
any spacer/tabs. Radiused slot so you don’t the long end of a J-bar style Panhard bar. After
have to re-square the rear end after adjust- loosening the two Allen bolts, the clamp may be slid
ments. Aluminum brackets fit 2" x 2" tubing. up or down on the chassis tube to adjust the bar and
change roll center.
Part No. Description ALL60183
Inside/Outside Mounting Part No. Description
ALL60246 ALL60182 1-1/2" I.D.
(Most Modifieds and GRT)
Center/Inside Mounting (Mastersbilt, ALL60183 1-3/4" I.D.
ALL60247 ALL60247
Barry Wright, Hughes)
ALL60248 Outside /Center Mounting (Rocket) FORD 9" PANHARD BAR BRACKETS
ALL60249 Center Mounting Ford center section brackets are 1/2" thick steel or aluminum. Each has four
3/4"-16 mount holes to provide 3.375" of adjustment. Both have dual patterns
CLAMP-ON PANHARD BAR BRACKETS and may be flipped to accommodate right- or left-hand Panhard bars. Both
Adjustable steel or aluminum brackets clamp to square tubing, providing attach with five bolts.
multiple Panhard bar mounting locations. Brackets are tapped for 3/4"-10 4 EQUALLY SPACED HOLES
bolts. Steel brackets have outer holes 5" apart. Aluminum brackets have outer ON 1.125" CENTERS
holes 5.5" apart. Hole measurements are center-to-center.

6.625" ALL60177
3.375"
ALL60245
8.000"
ALL60240 Part No. Description
ALL60176 Steel Bracket
Part No. Description
Steel Brackets ALL60177 Aluminum Bracket
ALL60240 For 2" x 2" Tubing
ALL60244 For 1-1/2" x 1-1/2" Tubing DOUBLE-SIDED FORD 9"
Aluminum Brackets PANHARD BAR BRACKETS
ALL60243 Straight, 2.5 Lbs., For 2" x 2" Tubing Double-sided, brackets are made of 1/2" steel and accept a right- or left-
ALL60245 Angled, 2.0 Lbs., For 2" x 2" Tubing hand Panhard bar without alteration. Standard thread (3/4"-16") or 3/4" slotted
type.
INTERNAL SCREW STYLE
PANHARD BAR ADJUSTERS ALL56152
A screw bolt style adjuster is welded inside of the
tube. When welded in place of current ALL60173 ALL60175
mount, Panhard bar can
be easily adjusted by
turning the screw bolt.
Attach Panhard bar to
this adjuster with Allstar ALL60183 Clevis (not included). Rear Part No. Description
Panhard mount, 21" tall with 3" of adjustment. ALL60173 Slotted Double-Sided
ALL60175 Threaded Double-Sided
ALL99040 Replacement Spacer For ALL60173
