Page 144 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

WHEEL AND TIRE ACCESSORIES

STEEL WHEEL SPACERS WHEEL STUDS
Spacers fit 5x5 hubs with 5/8" studs and provide Larger-than-stock studs require re-drilling of stock flanges. Check sanction-
maximum tread width for adjustment of chassis ing body for wheel stud requirements. Package of 5.
weight distribution. Spacers are made from tough Underhead Thread Knurl Knurl
1018 steel and have a 3.5" I.D. and a 7" O.D. Part No. Size Thread Length Length Length Dia.
Part No. Description ALL44110 1/2"-20 Fine 2.000" 1.625" .650"* .589"
ALL44124 1/16" ALL44111 1/2"-20 Fine 1.875" 1.125" .500"* .675"
ALL44125 1/8" ALL44112 1/2"-20 Fine 2.250" 1.925" .650"* .619"
.560"
ALL44114
.685"
2.000"
5/8"-18
Fine
2.000"
ALL44126 1/4"
ALL44115 5/8"-11 Coarse 2.000" 1.375" .375" .690"
ALUMINUM WHEEL SPACERS ALL44117 5/8"-11 Coarse 2.750" 2.125" .375" .690"
.725"
Coarse
2.125"
ALL44116
2.750"
5/8"-11
.690"
Change wheel offset without changing wheels! Uni- ALL44113 5/8"-11 Coarse 3.750" 3.125" .375" .690"
versal design fits 5 on 4-1/2", 5 on 4-3/4" and 5 on 5" ALL44119 5/8"-11 Coarse 3.750" 3.125" .725" .690"
patterns. Uses 5/8" stud slot to aid in centering. * Length with shoulder.
Part No. Description
ALL44216 1/4" ALL44110
ALL44217 1/2"
ALL44218 3/4" 1/2"-20 x 2" Long, Fine Thread, .589" Dia.
ALL44219 1" Knurl. .650"
ALUMINUM WHEEL SPACERS ALL44111
Spacers are available in 1/2", 3/4" and 1" thicknesses 1/2"-20 x 1-7/8" Long, Fine Thread,
and fit 4-1/2", 4-3/4" and 5" bolt circle patterns. Spacers .675" Dia. Knurl.
increase track width, requiring less wheel offset. Sold .500"
each. 1.900"
Part No. Description ALL44112
ALL44121 1/2" 1/2"-20 x 2-1/4" Long, Fine Thread,
ALL44122 3/4" .619" Dia. Knurl.
ALL44123 1" .650"
Note: 4-1/2" and 4-3/4" bolt patterns have 1/2" holes; 5" bolt pattern has
5/8" holes.
ALL44114
5/8"-18 x 2" Long, Fine Thread,
PLASTIC WHEEL SPACERS .685" Dia. Knurl. .560"
Reduce unsprung weight by up to 80%! Structural
composite spacers have been tested and can withstand ALL44115
high heat and high side forces in asphalt use. Must be
torqued for proper break-in. Sold each. 5/8"-11 x 2" Long, Coarse Thread,
Description Thickness Part No. .690" Dia. Knurl.
5x5 And 5x4-3/4" 1/4" ALL44202 .375"
5x5 And 5x4-3/4" 1/2" ALL44204
Wide 5 1/4" ALL44206 ALL44117
Wide 5 1/2" ALL44208 5/8"-11 x 2-3/4" Long, Coarse
Thread, .690" Dia. Knurl.
.375"
ALUMINUM WIDE 5
WHEEL SPACERS ALL44116
One-piece aluminum spacer moves Wide 5 wheel 5/8"-11 x 2-3/4" Long, Coarse
outboard. Sold each. Thread, .690" Dia. Knurl.
Part No. Description .725"
ALL44129 1/8" Thick
ALL44127 1/4" Thick ALL44113
5/8-11 x 3-3/4" Long, Coarse
THREADED WHEEL SPACERS Thread, .690" Dia. Knurl.
Aluminum spacers thread directly onto wheel studs of Wide 5 hubs with 5/8"-
11 threads. Hex design is easily installed and removed. Longer studs may be .375"
required when using spacers. Package of 5.
Part No. Description ALL44119
ALL44210 1/4"
ALL44211 3/8" 5/8"-11 x 3-3/4" Long, .725"
ALL44212 1/2" Coarse Thread, .690" Dia. Knurl.
ALL44213 5/8"
ALL44214 3/4"
ALL44215 1"
