Page 142 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

TRANSMISSION COMPONENTS

TRANSMISSION COOLERS BELLHOUSING DOWEL PINS
Universal coolers reduce operating ALL26700 Steel dowel pins are approximately 1/2" longer
temperature of the fluid, extend than stock pins and are required when running
life of the transmission and provide an engine mid-plate, rear motor mounts or an
better performance. Use as a stand aftermarket bellhousing. These extended length
alone cooler or as an auxiliary unit pins also help with alignment when installing an engine. ALL38152
to increase cooling capacity of Pins fit most GM blocks and are sold in pairs.
a stock system. Increased Part No. Description
cooling is recommended ALL38150 Solid Pins
when using a high stall ALL38152 Hollow Pins
converter, or if the vehicle is
used for towing. Choose from universal cool- SOLID TRANSMISSION MOUNT
ers with 3/8" barbed fittings, rubber hose, clamps and mounting kit, or -6AN ALL38070
coolers with standard -6AN male fittings and mounting kit. Solid 3/16" steel mount fits most TH350,
Part No. Overall Size Core Size GVW TH400, Powerglide, and all Borg Warner,
Coolers With 3/8" Barbed Fittings Muncie, and Chrysler 4-speed transmissions.
ALL26700 12" x 5" 9" x 5" 10,000 Lb
ALL26702 15" x 5" 12" x 5" 12,000 Lb Eliminates twisting, flex, and distortion. Not
ALL26704 12" x 7.5" 9" x 7.5" 16,000 Lb recommended for use with rubber engine mounts.
ALL26706 15" x 7.5" 12" x 7.5" 18,000 Lb
ALL26708 16" x 10" 12" x 10" 20,000 Lb TRANSMISSION MOUNT BRACKET
ALL26709 20" x 10" 17" x 10" 26,000 Lb ALL38072
Coolers With -6AN Fittings May be welded to chassis to support manual or
ALL26711 12" x 5" 9" x 5" 10,000 Lb automatic transmissions. Steel bracket is 1/8"
ALL26712 15" x 5" 12" x 5" 12,000 Lb
ALL26714 12" x 7.5" 9" x 7.5" 16,000 Lb thick with 1" x 7/16" slots for mounting bolts.
ALL26716 15" x 7.5" 12" x 7.5" 18,000 Lb
ALL26718 20" x 7.5" 17" x 7.5" 20,000 Lb
ALL26719 20" x 10" 17" x 10" 26,000 Lb BERT TRANSMISSION
SUPPORT BRACKETS
FLEXPLATES Transmission support fastens to the rear tail
Stock replacement and SFI-approved shaft housing of Bert Late Model Standard and Ball
flexplates are available for small and big Spline transmissions adding support to bellhousing
block Chevy engines. Gold iridite plated, SFI- mounted dry sump oil pumps or directly to the chas-
approved plates meet 29.1 specs., are .035" sis. Multiple holes in bracket offer many different
thicker than stock and have dual (10-3/4" and support options.
11-1/2") converter bolt patterns unless speci- Part No. Description
fied. SFI flexplates have ring gears welded on ALL38075 Standard
both sides. ALL38076 Ball Spline
Stock
Replacement SFI Description Balanced CLUTCH DISCS FOR BERT
ALL26835 ALL26830 SB Chevy 153-Tooth Internally Quality discs are a must when rebuilding the internal clutch of Bert transmis-
ALL26836 ALL26831 SB Chevy 153-Tooth, 1986-Up Externally sions. Friction disc and steel plate sets are sold separately.
ALL26805 ALL26800 SB/BB Chevy 168-Tooth Internally Note: Friction discs need to be soaked in Type-F automatic transmission
ALL26806 ALL26801 SB Chevy 168-Tooth, 1986-Up Externally fluid for at least 2 hours before installation.
ALL26815 ALL26810 SB Chevy 400, 168-Tooth Externally
ALL26825 ALL26820 BB Chevy 454, 168-Tooth Externally

FLYWHEEL LOCKING TOOL SB/BB CHEVY
ALL96426
Place flywheel locking tool onto rear block dowel pins to Part No. Description
prevent the flywheel from turning while tightening or loos- ALL26950 Clutch Friction Discs 6-Pack
ening balancer bolts, flywheel bolts, clutch/pressure plate ALL26952 Steel Clutches 5-Pack
bolts or cam gear bolts. Locking tool works with 153 or 168
tooth flywheels and flexplates.

BALANCING PLATE
ALL26120
Install between crankshaft flange and
flexplate to use a Chevy 350 flexplate or
flywheel with a 400 crank.
