TOOLS AND PIT EQUIPMENT

SET-UP STAND SHOCK EYE SOCKET
Before tire and wheel are removed, measure distance ALL64255
from center of hub to the ground. Remove the tire and wheel, The ideal tool for shock rebuilders or
replace with the set-up stand and adjust accordingly. Adjust- anyone that disassembles shocks on
ments can be made with car at exact ride height with the wheel a regular basis! Unique socket safely
and tire out of the way. Sold each. removes and installs the shock rod end
Part No. Description without risk of damage to the spherical ball.
ALL10664 5x5 Steel socket contacts the outer housing of
ALL10666 Wide 5 1/2" rod ends up to .640" wide and has a
1/2" drive for ratchet or impact use.

SHOCK WORKSTATION
ALL64264
The all in one shock worksta-
SET-UP TOOL ALL10668 tion holds shock bodies in the
upright position for ease of shaft
Tool replaces the front coil-over shock assembly to simulate range of removal or assembly and holds shock shafts vertical or
front suspension movement for checking bump steer and roll center. Hex horizontal for easier repairs or revalving. Aluminum construction
head, threaded shaft raises and lowers suspension to simulate racing con- workstation can be placed in a vise and has 1/4" threaded holes for custom
ditions. Jam nuts can be positioned to limit rebound and compression. Not mounting.
designed to support total vehicle weight, only suspension components.
UPPER BALL JOINT WRENCH SHOCK WORKSTATION BASE
ALL11190 ALL64267
Wrench is designed to remove Steel base is helpful when mounting
and install common upper screw- Allstar workstation (ALL64264) in a
in upper ball joint that are 1.900" wide (ALL56214). trailer or to a shop workbench. Mount-
ing hardware included.

SUSPENSION TUBE SET UP TOOL SHOCK DRIP CUP ALL64265
ALL10676 No more messy oil soaked rags or shock oil dripping
onto the workbench. Shock drip cup has a specially
designed rubber seal that conforms to a broad range of
shocks and holds cup in place. Fits 1-1/2" to 2-1/8" O.D.
Slide rule device quickly measures and duplicates shock bodies.
suspension or steering tube distances with 1/2", 5/8" and Part No. Description
3/4" rod ends. Set-up tool has an engraved scale with Replacement Part
1/16" increments for durability and accuracy. ALL99290 Drip Cup Seal
ROD END CENTERING KIT ALL10672 SHOCK RACKS
Compact inserts are placed into rod ends of suspen-
sion, steering or other tube assemblies to quickly Shock rack holds four
measure and adjust on the workbench or other flat shocks with 2.5" springs
surface with any standard tape measure. Inserts and easily mounts to
can be used on assemblies with 1/4", 3/8", 1/2", trailer, shop wall or
5/8" and 3/4" rod ends. pit cart. Rack is
designed to hold
shocks in place by pushing
ADJUSTABLE PANHARD BAR WRENCH shock rod end or eye over the outer o-ring
ALL11192 or alternatively, the outer o-ring may be removed
Wrench is designed to work with adjust- to expose a predrilled hole for a hair pin clip such as
able panhard bars with 1-3/8" adjusters. ALL18442 which are sold separately.
Shorter than a standard wrench, this Part No. Description
wrench is convenient for making adjustments in tight areas. ALL12212 Standard Rack
ALL12211 Adjustable Base Rack
SHOCK INFLATION TOOL Replacement Part ALL12213 ALL18442
ALL64260 ALL12213 Shock Pin, O-Ring and Bolt
Shock inflation tool threads onto shock Schrader valves. Fill Related Part
valve and 0-300 PSI gauge head rotate independently, ALL18442 1-5/8" Hairpin, 2-Pack
360°, for easy filling and reading. Complete with built-
in bleeder and includes a protective storage case.
