TOOLS AND PIT EQUIPMENT

TIRE GRINDING DISCS TOE PLATES
Grind off the hardened outer “skin” on used dirt track tires and create round, Aluminum plates simplify setting of toe-
aggressive sipes to increase traction. Use caution when handling and storing in and toe-out. Plates fit against outside
nail head disc, pins are needle sharp. edges of tires. Using two tape measures
(sold separately), measure the distance ALL10117
front and rear, between plates. The
difference in tape readings is the toe
setting. Deluxe plates have radiused
edges, slots for narrow and wide tape
measures and are 9" tall x 23" wide
to work with vehicles with smaller
ALL44180 ALL44181 ALL44182 ALL44183 ALL44196 wheel openings. Standard plates ALL10119
are 1/2" thick, 11" tall x 32" wide
Part No. Description Diameter Arbor Hole
ALL44180 Rounded Disc, 23 Grit 4" 5/8" and work well for vehicles with larger wheels and wheel openings. Set of two
plates.
ALL44181 Flat Disc, 23 Grit 4" 5/8" Part No. Description
ALL44182 Rounded Disc, 16 Grit 7" 7/8" ALL10117 Standard
ALL44183 Nail Head Disc 7" 7/8" ALL10119 Deluxe
ALL44196 Nail Head Disc 8" 5/8"
Safety Note: To prevent bodily injury the tire must be mounted on the car TOE GAUGE ALL10118
or secured in a tire holder. Eye and hand protection is required.
Check toe quickly
and easily. Allows one
BEAD BREAKERS person operation and
Convenient tool makes quick work the ability to check front
of breaking down even the most and rear toe dimension
stubborn tire beads. Durable from the front of the car
steel construction with without removing tool. Adjust stop
rubber hand grips. against front sidewall of tires, slide
Standard ALL44028 tool to rear sidewall and the difference
and wide is the amount of toe out. Tool adjusts to
jaw breakers measure from 49" to a maximum width of 89".
are for use with most 15" wheels. The adjustable arm version ALL44028,
allows bead breaker to be used on most 10", 13" or 15" wheels simply by CASTER PLATE ALL10752
changing the length of the arm. Wide jaw bead breaker works well with soft Not sure if you turned your wheels the same amount
sidewall tires helping prevent damage to sidewall. Clamp the hook and inside each time when adjusting caster settings on your race car?
jaw against the rim, while maintaining slight pressure on the outside handle Unless you have expensive turn plates, you’re never certain,
press down on the inside handle using the outer jaws to separate the tire from until now. This quick reference gauge positions under the up-
the rim, moving around the rim as needed. Wide Jaw per ball joint nut, with markings facing up, to easily view. Place
Part No. Description a mark on the shock body or fabricate an indicator to use as a reference point.
ALL10105 Standard-Jaw Bead Breaker Std.
Standard-Jaw Bead Breaker
ALL44028 GROUND CLEARANCE
With Adjustable Arm
ALL10106 Wide-Jaw Bead Breaker INDICATOR ALL10725
Determine how close the frame is to ground on the
race track. These unique kits feature an aluminum
bracket that rivets to the frame with an adjustable
plastic wear rod. Sold each.
TIRE SPOONS Part No. Description
Steel tire spoons Replacement Component
help to mount and ALL10726 Wear Rods, 4-Pack
dismount tires ALL10103 ALL10104
after bead has been broken. Various sizes ALL44037 ALL44036
are available to work with most tire/wheel combinations. Small tool works well SET-UP PLATES
to fit inside tire during removal while rounded ends help prevent damage to tire Set-up plates are used for squaring and
and wheel. stringing chassis to ensure accurate chas- ALL10660
Part No. Description sis set-up by eliminating wheel and tire
ALL10103 24" Straight With Round End differences. Plates can also be used when
ALL10104 16" Curved With Flat End setting bump steer or checking axle tubes
ALL44037 16" Curved With Round End for straightness. Sold each.
ALL44036 9" Curved With Round End Part No. Description
ALL10660 5x5, ALL10662
16 FT. TAPE MEASURE 7" x 28" x 1/2" Thick
Wide 5,
ALL10675 ALL10662 12" x 28" x 1/2" Thick
16' x 3/4" blade has fractional markings
every 1/8" for quick reference.
