Page 139 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

TOOLS AND PIT EQUIPMENT

PINION CENTERING JIG QUICK CHANGE TUBE
ALL68370 INSTALL/REMOVAL TOOL ALL11350
Pinion centering jig fastens to the rear end housing and locates Install and remove quick change axle tubes.
the pinion centerline when building or narrowing housings. Ma- Secure support tool into a vice or to a work-
chined slots are designed to retain most tape measure ends for bench with optional brackets. Components are
accurate measurements. Applications include GM 12 and 14-Bolt, included to remove and install tubes with the
Dana 44 and 60, Chrysler 8-3/4", Ford 8.8" and 9" housings. turn of a wrench. An adapter for tubes with
Wide 5 or 5 on 5" hubs is also included.
FORD 9" SET UP CARRIER
ALL14169
Set up carrier takes the place
of the gear set on Ford 9" rear
end housings and will keep dirt
and debris out of the housing.
A pinion bracket can be ALL11355
attached to the cover so
the J-bar or Panhard bar
can be mounted for car
transportation. The tip
of the handle matches Part No. Description ALL11351
the centerline of the driveshaft Related Components
U-joint so driveshaft length can be easily measured. Gloss red powder coated ALL11355 Installation End Cap
finish. For Bolt-On and 2-7/8" Pin Wide 5 Tubes
Mounting Bracket Kit
ALL11351 For Quick Change Tube Install/Removal Tool
PINION YOKE WRENCH
ALL68372
Wrench fastens to most popular pinion flanges
and companion flanges to hold when setting bearing AXLE SPLINE TOOL
pre-load and tightening retaining bolt or nut. Wrench ALL66104
has provisions to work with 1/2" or 3/4" drive tool. Tool clamps in a vise to hold 31-spline
Center hole is 2" to clear most sockets. Universal slotted bolt patterns for 1/4",
5/16" and 3/8" fasteners for most AMC, Dana, Ford and GM yokes. axles. Assures perfect alignment for
maintenance or installation of axle
plugs used with Gold-Trac differentials.
REAR END
STATION BRACKETS T-HANDLE
ALL10178 AXLE PULLER
Stand adapter brackets fasten ALL66115
to adjustable arms of most engine All-in-one T-handle puller threads into
stands. Supports full size car and
light truck rear axle housings when axle for easy installation or removal. Tool
includes adapters to fit 3/8"-16 coarse or
servicing or replacing differential
gear sets. Position housing onto 3/8"-24 fine thread solid axles, and 3/4"-
16 fine thread gun-drilled axles.
arms and secure into place with Engine Stand
included retaining straps. Not Included
VAN MAY QUICK FIX TOOL
ALL10237
SPINDLE NUT SOCKETS Resurface Quick Change
Aluminum hex style spindle nut sockets fit 1/2" socket rear end snout with the
wrenches. rear end still in the car using
the quick fix tool, developed
Part No. Description by sprint car owner/driver
ALL10110 2-3/8" Spindle Nut Socket For 2.0" Pin, Van May. Set up tool on output shaft
Allstar, PCR 5x5 And Most Wide 5 Hubs
2-7/8" Spindle Nut Socket For 2.5" Pin, and rotate cutter to produce a surface 90° to the shaft.
ALL10115 Instructions included.
Allstar, AFCO, Winters And SCP 5x5 Hubs
SHIM KIT ALL10238
For ALL10237, contains one each, .012", .016",
.022" thickness shim.

JEFF CADE JOHN BERGLUND
138
