Page 152 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

AFC1020 AFC1030 AFC1032
AFC1021 AFC1031 AFC1033
STEEL BODY TWIN TUBE SHOCK ABSORBERS STEEL BODY AFC1022 AFC1035 AFC1034
Steel body, twin tube shocks fit dirt modifieds with swing arm or 4-link STOCK MOUNT
suspensions. Shocks are offered in small or big body designs. SHOCK ABSORBERS
Comp. Extended Shocks have stock appearing bodies
Part No. Stroke Valving Length Length
10 Series to meet track rules and specialized
Non-Adjustable Big Body (2.02" O.D.) valving for oval track racing.
AFC1073 7" 3 12.75" 19.50" Compressed Extended
AFC1074 7" 4 12.75" 19.50" Part No. Description Valving Length Length Mount
AFC1074-6 7" 4-6 12.75" 19.50" GM Full- and Mid-Size, 1970-81 Camaro/Firebird,
AFC1074-8 7" 4-8 12.75" 19.50" 1965-86 Ford Full- and Mid-Size, Mercury Montego/
AFC1074-12* 7" 4-12 12.75" 19.50" Cougar
AFC1075 7" 5 12.75" 19.50" AFC1020 50/50 Extra Heavy 7 9.375" 13.375" Front
AFC1075-3 7" 5-3 12.75" 19.50" AFC1021 50/50 Heavy 6 9.375" 13.375" Front
AFC1075-9 7" 5-9 12.75" 19.50" AFC1022 80/20 7-4 9.375" 13.375" Front
AFC1079-1 7" Damper 12.75" 19.50" 1955-86 GM Full- and Mid-Size, 1964-88 Malibu/
AFC1093 9" 3 14.75" 23.50" Chevelle/Monte Carlo/Cutlass/Grand Prix/LeMans/
AFC1093-5 9" 3-5 14.75" 23.50" Tempest/Skylark/Regal; 1968-79 Nova
AFC1094 9" 4 14.75" 23.50" AFC1030 50/50 Medium 5 13.00" 21.00" Rear
AFC1095 9" 5 14.75" 23.50" AFC1031 50/50 Heavy 6 13.00" 21.00" Rear
12 Series AFC1035 40/60 3-5 13.00" 21.00" Rear
Sealed Body Fixed Bearing Big Body (2.02" O.D.) 1970-81 Camaro/Firebird
AFC1273FB 7" 3 12.375" 19.250" AFC1032 50/50 Medium 5 14.50" 22.50" Rear
AFC1274FB 7" 4 12.375" 19.250" AFC1033 50/50 Heavy 6 14.50" 22.50" Rear
AFC1275FB 7" 5 12.375" 19.250" AFC1034 40/60 3-5 14.50" 22.50" Rear
AFC1275-3FB 7" 5-3 12.375" 19.250" 1979-93 Ford Mustang
AFC1276FB 7" 6 12.375" 19.250" AFC1043 50/50 Medium 5 13.00" 21.50" Rear
AFC1276-2FB 7" 6-2 12.375" 19.250"
AFC1276-4FB 7" 6-4 12.375" 19.250"
AFC1279-1FB 7" 9-1 12.375" 19.250" SHOCK ABSORBER REBUILDING ACCESSORIES
AFC1293FB 9" 3 14.375" 23.250" AFCMT/TTSB
AFC1293-5FB 9" 3-5 14.375" 23.250"
AFC1294FB 9" 4 14.375" 23.250"
AFC1295FB 9" 5 14.375" 23.250" AFCA700500175
15 Series
Non-Adjustable Small Body (1.64" O.D.)
AFC1551 5" 1 10.70" 17.70"
AFC1554 5" 4 10.70" 17.70"
AFC1562 6" 2 11.50" 17.50"
AFC1563 6" 3 11.50" 17.50" AFCA700500058
AFC1564 6" 4 11.50" 17.50" Part No. Description
AFC1573-5 7" 3-5 12.70" 19.70" Shock Rebuild Kit, Main Shims, All AFCO Shocks
AFC1574 7" 4 12.70" 19.70" AFCMT/TTSB (Except 16 Series)
AFC1575 7" 5 12.70" 19.70" AFCA700500058 Shock Bleeder Tool, Twin Tube Shocks
AFC1575-3 7" 5-3 12.70" 19.70" AFCA700500175 Twin Tube Rod Guide Wrench, Big Body Shocks
AFC1576 7" 6 12.70" 19.70" Shock Absorber Overflow Cup, Used With Small
* Very stiff rebound. AFC550000302 And Big Body, And Quarter Midget Shocks

STEEL SEALED 14 SERIES
BIG BODY COIL-OVER SHOCK ABSORBERS
Ideal for dirt modifieds, steel, twin tube shock absorbers have large SHOCK ABSORBER ROD ENDS
(2.02" O.D.) sealed bodies to accept coil-overs. Coil-over kit must be purchased AND EXTENSIONS
separately. Use AFC20125A for 5" sleeve kit, or AFC20125A-7 for 7" sleeve kit. Part No. Description
Comp. Extended AFC1004 11, 13 R-Series Rod End, Std. Length, Coil-Over Style
Part No. Stroke Valving Length Length AFC20176 13 T-Series Rod End, Standard
AFC1473 7" 3 12.375" 19.250" AFC20176S 19, 23, 24, 25, 55, 56,
AFC1473-5 7" 3-5 12.375" 19.250" 57 And 58 Series Rod End, Standard, Steel
AFC1474 7" 4 12.375" 19.250" AFC20176-1 13 T-Series Rod End, 1" Longer Standard
AFC1474-6 7" 4-6 12.375" 19.250" AFC20176-2 13 T-Series Rod End, 2" Longer Standard
AFC1475 7" 5 12.375" 19.250" AFC20177 M2, T2, Std. Rod End, Adjustable
AFC1475-3 7" 5-3 12.375" 19.250" AFC20177-1C Silver Series Rod End, 1" Longer Adjustable
AFC1476 7" 6 12.375" 19.250" AFC20177-2C Silver Series Rod End, 2" Longer Adjustable
AFC1476-2 7" 6-2 12.375" 19.250" AFC20177-2 M2, T2, 2" Longer Rod End, Adjustable
AFC1477 7" 7 12.375" 19.250" AFC20180 11, 13 R-Series 1" Shaft Extension, 9/16"
AFC1479-1 7" 9-1 12.375" 19.250" AFC20180-1 11, 13 R-Series 2" Shaft Extension, 9/16"
AFC1493 9" 3 14.375" 23.250"
AFC1493-5 9" 3-5 14.375" 23.250"
AFC1494 9" 4 14.375" 23.250" SHOCK BUMPERS
AFC1495 9" 5 14.375" 23.250" Convoluted bumpers prevent bottoming shock absorber out.
AFC1495-3 9" 5-3 14.375" 23.250" Part No. Description AFC20173
AFC1496 9" 6 14.375" 23.250" AFC20173 Aluminum Cone, For Convoluted Shock Bumper
AFC1497-2 9" 7-2 14.375" 23.250" AFC223527 White Convoluted Shock Bumper Only, Standard
AFC223533 White Convoluted Shock Bumper Only, Medium/Hard
