GM TRAILING ARM BRACKETS REINFORCED FRONT SEGMENT LEAF SPRINGS
AFC20285
Brackets weld to 3" axle tubes to accept stock GM
lower control arms. Sold in pairs.

Secondary leaf design features a 10-15% stiffer front segment that provides
increased forward bite, quicker throttle response and improved spring
PANHARD BAR PINION MOUNTS durability. Springs additionally reduce wheelbase variations during braking or
9" FORD STEEL PINION MOUNT acceleration to improve overall handling.
Car
AFC20220 Part No. Description Weight Actual Nominal
Rate
Arch
Steel mount is drilled for LH or RH mount. AFC20228RF Camaro Type 2,500-3,000 6-3/8" 176
AFC20228HDRF Camaro Type 3,000-3,400 6-3/8" 205
AFC20231HDRF Chrysler Type 2,800-3,200 6-5/8" 166
9" FORD STEEL DOUBLE SIDED LEAF SPRING ACCESSORIES
PINION MOUNT AFC20220-1 U-BOLTS
Double-sided design enables relocation and lower U-bolts have 4" of threads and fit 3" axle tubes. Tall nuts have
placement of Panhard bar without removing the maximum thread engagement.
bracket. Part No. Description
AFC20238 8" U-Bolts, Sold Individually
AFC20238-9 9.5" U-Bolts, Sold Individually
SHACKLES
9" FORD STEEL PINION MOUNT Part No. Description AFC20235
AFC20296 AFC20235 Aluminum Shackle Plates,
Sold Individually
Steel mount is drilled for LH or RH installation and AFC20281 Steel Shackle Plates, Sold Individually
lowers placement of Panhard bar. Shackle Bolt Kit, Eliminates Rubber
AFC20235-2
Bushing In Chrysler Springs
LEAF SPRING PIVOT BUSHING
RETAINER RING AFC20352HD AFC20229P
Heavy duty, bolt-on retainer ring is made of 1/4" thick steel. Replaces rubber bushing in Chrysler type springs
Fits all 3" axle tubes. so front spring eye can rotate and twist for more
consistent handling.
MULTI-LEAF SPRINGS
LEAF SPRING SLIDERS
Roller bearing design replaces traditional shackles,
preventing suspension binding. Designed for use with
2-1/2" wide leaf springs, slider includes a 1-1/2" O.D.
bushing.
The same AFCO quality, but with tapered leaves, PTFE rub blocks between Part No. Description
leaves, and front bushings. AFC200036 Leaf Spring Slider, Camaro Type
AFC20236S Leaf Spring Slider, Chrysler Type
Car Actual Nominal
Part No. Description Weight Arch Rate
Chrysler Multi-Leaf Springs LOWER SPRING PLATES AFC20250
Chrysler Spring, Steel plate with shock mount.
AFC20231 2,300-2,800 lbs. 6-5/8" 142
5" Arch Part No. Description
Chrysler Spring, AFC20249 LH Spring Plate
AFC20231MHD 2,600-3,000 lbs. 6-5/8" 152 AFC20250 RH Spring Plate
5" Arch
Chrysler Spring,
AFC20231HD 2,800-3,200 lbs. 6-5/8" 166 NYLON FRONT EYE BUSHING
5" Arch
Chrysler Spring, AFC20229N
AFC20231XHD 3,100-3,500 lbs. 6-5/8" 194
5" Arch Three-piece Chrysler style bushing lets front eye rotate
Camaro Multi-Leaf Springs as spring moves.
AFC20228LW Camaro Spring 2,300-2,600 lbs. 6-3/8" 153
AFC20228 Camaro Spring 2,500-3,000 lbs. 6-3/8" 176 UNIVERSAL FRONT SPRING MOUNT
AFC20228HD Camaro Spring 3,000-3,400 lbs. 6-3/8" 205 AFC50200
AFC20228XHD Camaro Spring 3,000-3,400 lbs. 6-3/8" 238 Mount may be used with Chrysler style leaf springs.
