RACING BRAKE ROTORS PILLAR VANE HYBRID ROTORS
AFCO racing brake rotors are precision machined Hybrid design rotors, which combine the
and double disc ground to provide exceptional strength of the ‘75-81 Ford Granada hub with
flatness. Available Pillar Vane rotors offer increased the lightweight design of the GM metric brake
strength, reduced weight and improved cooling. rotor, include the addition of pillar vane technol-
Choose from flat, slotted or drilled rotors. All rotors ogy, which improves brake cooling and reduces
listed include a 8-bolt x 7" bolt circle. unsprung weight. Assemblies are 10.13” diameter,
Bolt include extra long 5/8” coarse thread studs on a
Part No. Description Thickness Circle Dia. Weight 5 x 5” pattern and feature installed races. Choose
Pillar Vane Rotors from flat or slotted rotors. Requires AFC9851-8551
AFC6640100 Flat Rotor .810" 7" 11.75" 8.2 lbs. installation kit.
AFC6640101 Flat Rotor 1.25" 7" 11.75" 10.7 lbs. Part No. Description
AFC6640103 Flat Rotor 1.25" 7" 12.19" 10.9 lbs. Pillar Vane Flat Hybrid Rotor,
AFC6640104 Slotted Rotor, RH .810" 7" 11.75" 8.1 lbs. AFC6640138 IMCA/USMTS/UMP/WISSOTA Approved
AFC6640105 Slotted Rotor, LH .810" 7" 11.75" 8.1 lbs. AFC6640139 Pillar Vane Slotted Hybrid Rotor, USMTS/UMP Approved
AFC6640106 Slotted Rotor, RH 1.25" 7" 11.75" 10.6 lbs.
AFC6640107 Slotted Rotor, LH 1.25" 7" 11.75" 10.6 lbs. PRECISION PINTO SPINDLES
AFC6640112 Drilled Rotor .810" 7" 11.75" 7.1 lbs.
AFC6640114 Drilled Rotor 1.25" 7" 11.75" 9.6 lbs. Pinto spindles are manufactured, precision machined and
AFC6640116 Drilled Rotor .810" 7" 12.19" 7.3 lbs. CNC blueprinted to the OEM dimensions, ensuring that front
Straight Vane Rotors end geometry is true.
AFC9850-6020 Straight Vane Rotor 1.25" 7" 11.75" 8.9 lbs. Part No. Description
AFC9850-6021 Straight Vane Rotor .810" 7" 11.75" 8.2 lbs. AFC100152 Pinto Spindle, Left, 7.5° Pin
AFC9850-6120 Straight/Drilled Rotor 1.25" 7" 11.75" 7.9 lbs. AFC100153 Pinto Spindle, Right, 7.5° Pin
Curved Vane Rotors
AFC9850-8020 Curved Vane Rotor, LH 1.25" 7" 11.75" 8.9 lbs.
AFC9850-8021 Curved Vane Rotor, RH 1.25" 7" 11.75" 8.9 lbs. BRAKE PEDAL ASSEMBLIES
Forged aluminum H-beam pedal assemblies are rigid and
durable. An ultra-strong upper mount eliminates the
possibility of flex. A high strength bias bar, rounded clevis
and integral bias bearing simplify brake bias adjustments.
STOCK BRAKE ROTORS Pedals include industrial grade anti-skid foot pads and provide
a 6.25:1 pedal ratio. Choose from forward or reverse mount
Stock appearing brake rotors meet most sanction- assemblies. Master cylinders sold separately.
ing body requirements for modifieds, street stocks Part No. Description AFC6610000
and hobby stocks. Rotors include races and 5/8" AFC6610000 Reverse Mount Pedal Assembly
coarse thread studs installed on 5 x 5 bolt pattern. AFC6610001 Forward Mount Pedal Assembly
Bolt
Part No. Description Thickness Circle Dia.
AFC9850-6500 GM Metric Rotor, 1979-Up 1.00" 5 x 5 10.50" INTEGRAL RESERVOIR
AFC9850-6505* Hybrid/Pinto/Mustang II Spindle .813" 5 x 5 10.13" MASTER CYLINDERS
AFC9850-6510 Ford Granada, 1975-81 .875" 5 x 5 11.00" All new AFCO aluminum master cylinders have high capacity
AFC6640124* Hybrid/Flat Pillar Vane Rotor .813" 5 x 5 10.13" reservoirs and precise bores. External return spring provides
Hybrid/LH
AFC6640125* Pillar Vane Slotted Rotor .813" 5 x 5 10.13" positive pedal feel and prolongs pad life. Dual
Hybrid/RH mounting bolt pattern and use of standard
AFC6640126* .813" 5 x 5 10.13" 1/8" NPT port fittings allow easy installation.
Pillar Vane Slotted Rotor
*Mount with Hybrid caliper brackets AFC40122PL and AFC40122PR. Master Cylinder Master Cylinder
Description Kit Rebuild Kit
REPLACEMENT/ACCESSORY COMPONENTS 3/4" Bore Master Cylinder AFC6620010 AFC6690110*
Master Bearing Hub Hub 7/8" Bore Master Cylinder AFC6620011 AFC6690111*
Description Install Kit Kit Seal Cap 1" Bore Master Cylinder AFC6620012 AFC6690112*
GM Metric Rotor AFC9851-8550 AFC9851-8500 AFC9851-8520 AFC9851-8501 * Kits for master cylinders manufactured after 1-1-13.
Hybrid Rotor AFC9851-8551 – – –
Ford AFC9851-8552 AFC9851-8510 AFC9851-8521 AFC9851-8502
Granada Rotor
REMOTE RESERVOIR
HYBRID GM 1979-UP ROTOR MASTER CYLINDERS
AFC6640137 Lightweight and compact, aluminum master
Hybrid brake rotor assembly combines the strength cylinder includes an aluminum bore and hard anodized
of the 1975-81 Ford Granada hub with the lightweight piston for exceptional reliability, while an external return spring offers superior
design of the GM metric brake rotor. Stock-appearing pedal feel. Popular dual mounting bolt pattern and 1/8" NPT ports allow easy
assembly, which fits new IMCA spindle, is 10.5" installation.
diameter x 1.00" thick, includes extra long 5/8" studs Master Cylinder Master Cylinder
on a 5 x 5" pattern and features installed races. Ap- Description Kit Rebuild Kit
proved by IMCA, UMP, USMTS and WISSOTA. Requires 3/4" Bore Master Cylinder AFC6620110 AFC6690110
AFC9851-8550 installation kit. 7/8" Bore Master Cylinder AFC6620111 AFC6690111
1" Bore Master Cylinder AFC6620112 AFC6690112

158
