SMALL BLOCK CHEVY ELIMINATOR SMALL BLOCK FORD RENEGADE
ALUMINUM CYLINDER HEADS ALUMINUM CYLINDER HEADS
The Eliminator aluminum cylinder heads, with choice of Re-engineered from the ground up, Renegade
210cc, 220cc, 227cc and 235cc intake runners, have 20° cylinder head delivers improved air
valves and studs in the stock GM L98 location. flow, while maintaining exceptional
Race Ready 210cc and 227cc cylinder heads port velocity to small block Fords.
add 100% CNC-ported intake runners Aluminum heads are offered in
and are perfect for 350-400 cu. in.; 165cc, 185cc, 195cc, 205cc
the 227cc version is designed for and 220cc versions. Large,
larger cu. in. applications that see a 205cc runner heads are
minimum of 4500 RPM. Competition intended for 331-392 cu. in., while
Package heads, offered in 220cc, 227cc the 220cc is the perfect choice for the vast majority of 347-427 cu. in. race-
and 235cc versions, with 100% CNC-ported intake only applications. All heads are sold in pairs, completely assembled with
runners, are engineered for highly modified 350-434 cu. in. engines that oper- stainless valves, valve springs, retainers, locks and seals. Heads listed below
ate 4000-8000 RPM. All heads are sold in pairs, completely assembled (unless are engineered for stud mount rocker arms.
specified) with stainless valves, valve springs, retainers, locks and seals. Intake Comb. Int. Exh. Valve
Intake Comb. Spark Int. Exh. Part No. Description Runner Chamber Valve Valve Spring
Part No. Description Runner Chamber Plug Valve Valve AFR1399 Race Ready Assy. 165cc 58cc 1.900" 1.600" Dual/1.290"
Race Ready AFR1422 Race Ready Assy. 185cc 58cc 2.020" 1.600" Dual/1.290"
AFR1050 210cc 75cc Angle 2.080" 1.600" AFR1387 Race Ready Assy. 185cc 72cc 2.020" 1.600" Dual/1.290"
Assy. AFR1388 Race Ready Assy. 185cc 58cc 2.020" 1.600" Dual/1.290"
AFR1054 Race Ready 210cc 65cc Angle 2.080" 1.600" AFR1381 Race Ready Assy. 195cc 58cc 2.050" 1.600" Dual/1.270"
Assy. AFR1383 Race Ready Assy. 195cc 72cc 2.050" 1.600" Dual/1.270"
AFR1103 Comp. Pkg. Assy. 210cc 65cc Angle 2.080" 1.600" AFR1450* Race Ready Assy. 205cc 58cc 2.080" 1.600" Dual/1.550"
AFR1065* Comp. Pkg. Assy. 220cc 65cc Angle 2.100" 1.600" AFR1458* Race Ready Assy. 205cc 72cc 2.080" 1.600" Dual/1.550"
AFR1110 Comp. Pkg. Assy. 220cc 65cc Angle 2.100" 1.600" AFR1451* Race Ready Assy. 220cc 58cc 2.080" 1.600" Dual/1.550"
AFR1112 Comp. Pkg. Assy. 220cc 75cc Angle 2.100" 1.600" AFR1456* Race Ready Assy. 220cc 69cc 2.100" 1.570" Dual/1.550"
AFR1114 Comp. Pkg. Assy. 220cc 65cc Angle 2.100" 1.600" * 2.080" and larger valves require aftermarket pistons notched for valve
Race Ready clearance.
AFR1067 ‡ Assy. 227cc 75cc Angle 2.100" 1.600"
Race Ready SMALL BLOCK CHEVY
AFR1068 ‡ 227cc 65cc Angle 2.100" 1.600"
Assy. HS ROLLER ROCKER ARMS
AFR1120 ‡ Comp. Pkg. Assy. 227cc 75cc Angle 2.100" 1.600" AFR6036
AFR1121 ‡ Comp. Pkg. Assy. 227cc 65cc Angle 2.100" 1.600" Engineered specifically for AFR 220cc or 227cc cylinder
AFR1124 †‡ Comp. Pkg. Assy. 227cc 65cc Angle 2.100" 1.600" heads, 1.6 ratio aluminum roller rocker arms are designed
† Signifies spread port exhaust pattern for use with 7/16” studs and feature .050” offset. Sold in set of 16.
‡ Requires offset stud girdles
* Signifies competition CNC-ported
STUD GIRDLES
Billet aluminum construction stud girdles tie the rocker studs together,
SMALL BLOCK CHEVY increasing valvetrain alignment and durability.
TITAN TXR INTAKE MANIFOLD AFR4801
Innovative, composite plastic intake
manifold for small block Chevys
deliver 15 more horsepower than
comparable manifolds. The Titan
TXR runs up to 30° cooler than
traditional manifolds and AFR6200 AFR6208 AFR6207
weighs 9-11 lbs. less than Part No. Description
aluminum units. Modular AFR6200 SB Chevy L98, Eliminator 180cc, 195cc, 210cc And 220cc
design manifold includes AFR6208 SB Chevy, Offset For 227cc And 235cc
interchangeable runners, dual distributor hold downs and rubber Viton gaskets. AFR6207 SB Ford
Distributor clamp, (12) 3/8" bolts and washers included. Manifold has a 5.500"
carb height.

ALUMINUM
VALVE COVERS
Lightweight aluminum valve covers
are offered in polished or black pow-
der coat finishes and are engraved
with the AFR logo. Sold in pairs, com-
plete with breathers and grommets.
Black Polished
Application Part No. Part No.
SB Chevy, Tall AFR6705 AFR6704
SB Chevy, Short AFR6707 –
SB Ford, Tall AFR6715 AFR6714
SB Ford, Short AFR6717 AFR6716
