Page 681 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

PEDAL ASSEMBLIES WIL340-13574 PEDAL REMOTE MASTER CYLINDER
A non-slip pad is installed on each pedal, and both the MOUNT WIL340-4630
pedal and base are coated with a corrosion-proof finish. A Ideal for dirt modifieds where the master cylinder must
spherical pivot bearing in the center of the bar, superior bal- be mounted in a remote location due to space constraints.
ance bar and clevis insure proper pushrod alignment. Master Cast aluminum housed unit is typically mounted to the
cylinders must be purchased separately. left side chassis rail and includes a balance bar to
Part No. Description control two standard mount master cylinders with remote
Single Pedal/Single Master Or Clutch Cylinder Assemblies mounted reservoirs. Unit weighs just 1.8 lbs. and is
WIL340-13574 Reverse Swing Mount Assembly, Reverse Mount M/C, sold complete with adjuster knob.
6.0:1 Ratio, 12.02" Pedal Length
WIL340-13833 Floor Mount Assembly, Forward Mount M/C, 6.0:1 Ratio, 9.63" Pedal Length
WIL340-13834 Swing Mount Assembly, Forward Mount M/C, 7.0:1 Ratio, 12.1" Pedal Length REMOTE BRAKE BIAS ADJUSTER
Single Pedal/Dual Master Cylinder Assemblies WIL340-4990
Reverse Swing Mount Assembly, Reverse Mount M/C, 6.25:1 Ratio, 11.71"
WIL340-12509 When used with a balance bar, unit allows
Pedal Length
WIL340-13831 Floor Mount Assembly, Forward Mount M/C, 6.0:1 Ratio, 9.6" Pedal Length front-to-rear brake bias to be adjusted to suit
WIL340-13832 Swing Mount Assembly, Forward Mount M/C, 7.0:1 Ratio, 12.11" Pedal Length changing racing conditions. Bright blue knob
Reverse Swing Mount Assembly, includes special detent control for easy driver
WIL340-13837
Reverse Mount M/C, 5.0:1 Ratio, 10.02" Pedal Length adjustment. Sold complete with 5' cable,
Dual Pedal/Triple Master Cylinder Assemblies housing and two label faces for front-to-
WIL340-11295 Swing Mount Assembly, Forward Mount M/C, 6.25:1 Ratio, 12.05" Pedal Length rear or rear-to-front adjustments. Unit has 3/8"-24 threads to fit Wilwood and
Reverse Swing Mount Assembly,
WIL340-11299 Reverse Mount M/C, 6.25:1 Ratio, 11.89" Pedal Length most popular brake balance bars.
WIL340-13835 Reverse Swing Mount Assembly, Reverse Mount M/C,
5.0:1 Ratio, 10.02" Pedal Length CLUTCH PEDAL KITS
Reverse Swing Mount Assembly, Reverse Mount M/C, 6.25:1 Ratio, Lightweight Clutch Pedal Kits are offered in floor
WIL340-13836
11.89"/10.02" Pedal Lengths or swing mount versions. All-in-one kits are sold
Triple Pedal/Triple Master Cylinder Assemblies complete with forged adjustable clutch pedal as-
WIL340-12410 Floor Mount Assembly, Forward Mount M/C, 5.25:1 Ratio, 10.66" Pedal Length sembly, 3/4" bore integral reservoir master cylinder,
Floor Mount Assembly,
WIL340-12411* universal pull type slave cylinder and required
Forward Mount M/C, 5.25:1 Ratio, 10.66", Includes Throttle Link
Replacement Components hardware.
WIL340-1757 Balance Bar Assembly Only Part No. Description
* Includes throttle link. WIL341-15169 Floor Mount Clutch Pedal Kit, 6.0:1 Ratio, 9.63" Pedal Length
WIL341-15170 Swing Mount Clutch Pedal Kit, 7.0:1 Ratio, 12.1" Pedal Length
TRU-BAR Replacement Component
PEDAL ASSEMBLIES WIL330-13192 Clutch Clevis Only
Tru-Bar balance bar pedal assemblies use a fixed
trunnion bearing in the pedal arm with spherical heim end SLAVE CYLINDER WIL260-1333
pushrod attachments to deliver precise control of brake Alu mi num slave cylinder’s pull rod has
bias adjustment. Assemblies include a large, 7/16"-20 bar for longer travel for full
quick adjustments with a shouldered, 3/8" end that may be at- release of clutch
tached to a standard remote adjuster cable. Master cylinders must and a 7/8" bore x 1.25" stroke.
be purchased separately. WIL340-15072 Part No. Description
Part No. Description Replacement Component
Single Pedal/Dual Master Cylinder Assemblies WIL260-5524 Slave Cylinder Rebuild Kit
Swing Mount Brake Pedal,
WIL340-15076
Reverse Mount M/C, 5.1:1 Ratio, 10.14" Pedal Length KNOB STYLE PROPORTIONING VALVE
Swing Mount Brake Pedal,
WIL340-15077 Reverse Mount M/C, 6.25:1 Ratio, 11.88" Pedal Length WIL260-10922
WIL340-15078 Floor Mount Brake Pedal, Forward Mount M/C, 6.0:1 Ratio, 9.6" Pedal Length Adjustable Proportioning Valve features a
Swing Mount Brake Pedal, fine threaded adjuster for precise pressure
WIL340-15079
Forward Mount M/C, 7.0:1 Ratio, 12.12" Pedal Length adjustments from 100-1,000 PSI. Unit can
Dual Pedal/Triple Master Cylinder Assemblies deliver up to 57% reduction in line pressure.
WIL340-15072 Swing Mount Assembly, Forward Mount M/C, 6.25:1 Ratio, 12.07" Pedal Length Compact, lightweight assembly has 3/8"-24 ports and dual mounting
WIL340-15073 Swing Mount Assembly, Reverse Mount M/C, 5.0:1 Ratio, 10.14" Pedal Length
WIL340-15074 Swing Mount Assembly, Reverse Mount M/C, 6.25:1 Ratio, 11.88" Pedal Length holes to ease installation. May be used to adjust front to rear, side to side or
Swing Mount Assembly, single wheel brake bias.
WIL340-15075
Reverse Mount M/C, 6.25/5.1:1 Ratios, 11.88"/10.02" Pedal Lengths
LEVER STYLE
PROPORTIONING VALVE
BRAKE PEDAL WIL260-8420
REPLACEMENT PARTS Adjustable valve delivers precise
Part No. Description pressure, 100 to 1,000 PSI. Compact,
Clutch Pedal Lever, For WIL340-3342 forged aluminum valve can reduce in
WIL330-3345 Reverse Swing Mount Pedal Assembly, line pressure by as much as 57% at full release. Easily mounted with two .250"
6.25:1 Ratio dia. holes on 1.00" centers. Includes 1/8" NPT inlet and outlet ports and 1/8"
WIL330-11280 Brake Or Clutch Pedal Pad, Aluminum
NPT to 3/8"-24 brake line adapters.
WIL330-3345

680
