Page 682 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

COMPACT REMOTE HIGH VOLUME ALUMINUM
FLANGE MOUNT MASTER CYLINDERS MASTER CYLINDERS
Offering four combinations, compact Master cylinders have 26% more fluid capacity
and lightweight master cylinders, and include formed steel lids, bellows type
with small or large reservoir, may be gaskets, internal slosh baffles, and
remotely or directly mounted with up to WIL260-10371 standard mounting dimensions.
2" additional clearance between flange Master Cylinder Rebuild Kit Replacement
and outlet. Close tolerance cut-off and Description Part No. Part No. Lid And Gasket
equalization ports assure immediate 3/4" Bore Master Cylinder WIL260-6764 WIL260-6898 WIL330-13945
activation and heavy return springs offer smooth operation 7/8" Bore Master Cylinder WIL260-6765 WIL260-6899 WIL330-13945
and quick release. 1" Bore Master Cylinder WIL260-6766 WIL260-6900 WIL330-13945
Master Cylinder Kit Rebuild Kit
Description Part No. Part No. REPLACEMENT BAIL WIRE
5/8" Bore Master Cylinder WIL260-10371 WIL260-10513 RETAINER WIL300-6726
3/4" Bore Master Cylinder WIL260-10372 WIL260-10514
13/16" Bore Master Cylinder WIL260-10373 –
7/8" Bore Master Cylinder WIL260-10374 WIL260-10516 INTEGRAL RESERVOIR COMPACT
1" Bore Master Cylinder WIL260-10375 WIL260-10517 ALUMINUM MASTER CYLINDERS
1-1/8" Bore Master Cylinder WIL260-10376 – Compact, aluminum cylinders are ideal
for clutch or brake. Reservoir hold 1.4 oz.
COMPACT REMOTE and includes screw-on filler cap.
SIDE MOUNT MASTER CYLINDERS Part No. Description
Master cylinders are designed for WIL260-2636 .625" Bore
applications that have limited mount- WIL260-6579 .700" Bore
ing space, yet require the capacity of WIL260-1304 .750" Bore
a full size unit. Short and compact, TANDEM MASTER CYLINDER
3.37" body offers 2.16" of additional
clearance between the mounting WIL260-4893
boss and fluid outlet. Aluminum Durable housing has a large capacity plastic
bodied cylinders are black E-coated reservoir. Dual outlet, 1-1/16" bore cylinder
for corrosion resistance and are sold has stock components, factory-style mount
complete with small and large reservoirs. WIL260-12385 hole pattern and outlet thread size. Optional
Part No. Description universal mounting bracket kit with push rod
WIL260-12385 Compact Remote Master Cylinder, 3/4" Bore and dust boot available.
WIL260-12387 Compact Remote Master Cylinder, 7/8" Bore Part No. Description
WIL260-12388 Compact Remote Master Cylinder, 1" Bore WIL250-2406 Universal Bracket Kit; Master Cylinder To Firewall
WIL250-3677 Bracket Adapter Kit; Master Cylinder To Single Brake Pedal
COMPACT REMOTE WIL260-4894 Tandem Kit; Master Cylinder, Boot, Push Rod, And Retainer
ALUMINUM MASTER CYLINDERS WIL260-4896 1-1/16" Master Cylinder Rebuild Kit
Designed for cars with limited space and requires a
remote reservoir (not included). Fluid ports are TANDEM REMOTE MASTER CYLINDERS
up top for easy access. Bore sizes accommodate One of the safest, most effective methods of
compact brake calipers, short pedal actuating four wheel or dual caliper axle brake
ratios, and hydraulic clutches. systems. Master cylinder offers 50/50 output
Part No. Description from a 1" bore with 1.1" stroke. Offered in
WIL260-6087 Remote Master Cylinder, .625" Bore traditional or remote reservoir versions,
WIL260-6088 Remote Master Cylinder, .700" Bore cylinders may be bolted directly to Wilwood
WIL260-6089 Remote Master Cylinder, .750" Bore single mount pedals. Sold complete with
WIL260-11972 Remote Master Cylinder, .812" Bore 4 oz. reservoirs and supply hoses (where
applicable).
COMBINATION REMOTE Part No. Description
MASTER CYLINDER KITS WIL260-7563 Tandem Remote Master Cylinder, Includes Remote 4 Oz.
Reservoirs And Supply Hose
Each kit includes master cylinder with
3/8"-24 UNF outlets, large (10.7 oz.) WIL260-8794 Tandem Remote Master Cylinder
and small (4.0 oz.) reservoirs, remote
mounting bracket, remote inlet adapter, MASTER CYLINDER ACCESSORIES
remote hose, reservoir cap and hardware.
Part No. Description
Master Cylinder Kit Rebuild Kit
Description Part No. Part No. Remote Inlet Adapter, Combination
5/8" Master Cylinder Kit, 1.3" Stroke WIL260-3372 WIL260-3880 WIL260-3396 Remote And Tandem Remote
3/4" Master Cylinder Kit, 1.1" Stroke WIL260-3374 WIL260-3881 Master Cylinders
13/16" Master Cylinder, 1.1 Stroke WIL260-5920 – WIL260-5751 Remote Plastic Reservoir, 10.7 Ozs.
7/8" Master Cylinder Kit, 1.2" Stroke WIL260-3376 WIL260-3882 WIL260-10264 Inlet Adapter, Compact Remote
1" Master Cylinder Kit, 1.0" Stroke WIL260-3378 WIL260-3883 Master Cylinder
1-1/8" Master Cylinder Kit, 1.0" Stroke WIL260-3380 – Reservoir Kit, Includes 4.0 Oz. And WIL260-5751
WIL260-10500 7.2 Oz. Plastic Reservoirs, And
Supply Hose

681
