Page 691 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

FALCON ROLLER SLIDE TRANSMISSION FALCON LATE MODEL TRANSMISSION
WIN60120B WIN60100
Roller Slide transmission combines the benefits The Falcon has two forward speeds
of increased drive line travel, reduced and reverse. An integral hydraulically
maintenance and improved durabil- applied clutch is operational in both
ity. Unit telescopes a full low and reverse gear. High gear is
5-1/2" at the rear yoke, direct drive. A floating input shaft
allowing the drive line and contributes to positive high gear reten-
suspension to move forward tion and frictionless bearings support all
and rearward without inducing or limiting roll steer. Transmission has two for- rotating components with surprising durability. Weighs just 43 lbs.
ward speeds and reverse, while an integral hydraulic applied clutch operates Part No. Description
low and reverse. High gear is a direct drive 1:1 ratio and a floating 10-spline Replacement Components
(Bert/Brinn) input shaft offers positive high gear retention available. WIN61735 Clutch Gear
WIN61741 Sliding Gear
CHEVY WIN61743 Reverse Counter Shaft
6-1/4" DEEP ALUMINUM WIN61745 Transmission Case, Aluminum
WIN61847
Clutch Spring Spacer
FLYWHEEL HOUSING WIN61852-1 Clutch Disc, Steel, Each
Lightweight bellhousing has provisions for WIN61853-1 Clutch Disc, Friction, Each
a reverse mount starter and accepts belt or WIN61877 Aluminum Extension Housing
camshaft driven pumps and internal clutch late WIN61903 Output Shaft
model transmissions. Idler gear, starter ring gear, WIN62156 Side Cover Gasket
crank coupler with HTD gear and spacer shims WIN62221 27-Spline Slip Yoke, 4-7/8" Long, 1310 Series
are included. WIN62341 Idler Gear Return Spring
Chevy Crank Coupler, 18-Spline
Part No. Description WIN62348-18* Late Chevy Crank Coupler, For One-Piece Rear Main Seal
WIN62350-18
Aluminum Flywheel Housing,
WIN62843 WIN62354 Spacer, Clutch Gear
Includes Coupler For Falcon Transmission WIN62407* Input Collar
Aluminum Flywheel Housing,
WIN62843B WIN62409 Input Shaft 18/10-Spline, Use With Bert or Brinn 10-Spline Couplers
Includes Coupler For 10-Spline Bert/Brinn Transmission WIN62446 Early Chevy Crank Coupler, With 24-Tooth HTD
WIN64334 Bellhousing Filler Panel WIN62447 Crankshaft Coupler, 10-Spline With 22-Tooth HTD Pulley
WIN62901* Input Shaft 18/18
CT525 WIN62946-6 27-Spline Slip Yoke, 6" Long, 1310 Series
CRANKSHAFT ADAPTER WIN62946-8 27-Spline Slip Yoke, 8" Long, 1310 Series (Recommended)
Special adapter bolts directly to crankshaft of popular WIN63844-18 Late Chevy Crank Coupler/Ring Gear Assembly,
18-Spline, Ext. Balance
GM LS Series “525” crate motor or other LS engines and WIN67256 Front Input Seal
adapts it to early Chevy bolt pattern, allowing for com- WIN67257 Extension Housing Seal
patibility with popular crankshaft couplers. Requires WIN67259 Shifter Shaft Seal
WIN68938 bolts. WIN67480 O-Ring, Counter Shaft
Part No. Description WIN67481 O-Ring, Reverse Shaft
WIN64976 Chevy LS Series Crankshaft Adapter WIN67560 Thrust Washer, .093"
WIN68938 Crankshaft Adapter Bolts, 11mm, 6 Pcs. WIN67562 Thrust Bearing
WIN67574 Bearing, Extension Housing
WIN67691 Retaining Ring, Extension Housing Bearing
WIN67991 Roll Pin, Counter Shaft
WIN68035 Fill Plug
Rebuild Kit
Complete Rebuild Kit, Includes New Style Clutch Discs And
WIN62822-2
Steel PlatesTo Upgrade Older Style And Rebuild Current Models
* Included with transmission.

METAL RESCUE
RUST REMOVER BATH
Metal Rescue is a non-hazardous, easy, safe, clean
and effective method of rust removal without any of
the risks involving health or environmental concerns.
DRY COAT RUST PREVENTATIVE Usage is easy; simply immerse rusty parts in the
WSHWH003172 liquid for 5 minutes to 24 hours based on the amount
Water-based rust preventative is a significant advancement of rust, temperature of the liquid, and type of steel.
in corrosion protection technology, replacing solvent and oil- Metal Rescue removes the rust from the part and the
based corrosion inhibitors. After application, clear protective rust becomes suspended in the solution. Once rust is
coating dries to the touch and does not attract dirt or dust on removed, simply rinse part off and dry, and the part is
metal parts. Product is non-hazardous and washes off using ready for use. Sold in 1 quart, 1- and 5-gallon containers.
mild detergents. Sold in a 16 oz. bottle. 1 Quart 1 Gallon 5 Gallon
Description Part No. Part No. Part No.
Metal Rescue WSHWH290497 WSHWH290487 WSHWH570295
