SMALL BLOCK CHEVY 23° FORGED SMALL BLOCK CHEVY 23°
MAX SERIES FLAT TOP PISTON KITS HOLLOW DOME PISTONS
Max Series, 23° small block 350 Chevy kits utilize Small block Chevy 350 forged 2618 alloy pistons combine the benefits of
strutted, high strength 2618 alloy pistons with low hollow domes and a strutted, high strength design. Piston skirts are coated
friction metric piston rings. Flat top pistons feature with friction reducing ArmorGlide, while lateral gas ports aid compression seal-
ArmorGlide coated skirts for reduced scuffing and ing. Pistons accept .043", .043" and 3.0mm piston rings. Sold in sets of eight,
lateral gas ports for maximum compression sealing. complete with .927" x 2.250" piston pins and spiral locks.
Pistons are sold in sets of eight, complete with 1.2mm, Rod “0” Deck Comp. Dome
1.2mm and 3.0mm metric GFX piston rings, .927" x Part No. Bore Stroke Length Height At Height Volume
2.250" piston pins and spiral locks. WISK0128B3 4.030" 3.480" 6.000" 9.025" 1.250" 13.5cc
WISK0128B4 4.040" 3.480" 6.000" 9.025" 1.250" 13.5cc
Rod “0” Deck Comp. Dome
Part No. Bore Stroke Length Height At Height Volume WISK0129B3 4.030" 3.480" 6.125" 9.025" 1.125" 13.5cc
WISK0002X3 4.030" 3.480" 6.000" 8.990" 1.250" -5.7cc WISK0129B4 4.040" 3.480" 6.125" 9.025" 1.125" 13.5cc
WISK0002X4 4.040" 3.480" 6.000" 8.990" 1.250" -5.7cc
WISK0002X6 4.060" 3.480" 6.000" 8.990" 1.250" -5.7cc FORD 2.3L FLAT TOP PISTONS
WISK0003X3 4.030" 3.480" 5.700" 8.990" 1.550" -5.7cc
WISK0003X4 4.040" 3.480" 5.700" 8.990" 1.550" -5.7cc Popular for use with mini stocks, forged alloy 2618 flat
top pistons are machined for popular 1/16", 1/16" and
3/16" piston rings. Sold in sets of four, complete with 4140
WRIST PIN RETAINERS WISCS-24 chrome moly wrist pins and spiral locks.
Replacement, three-layer spiral locks fit Rod “0” Deck Comp. Dome
small block Chevys with .927" dia. wrist pins. Part No. Bore Stroke Length Height At Height Volume
Retainers are .075" thick x 1.010" free O.D. WISK120A3 3.810" 3.126" 5.205" 8.358" 1.590" -3.4cc
and sold in pairs. WISK120A4 3.820" 3.126" 5.205" 8.358" 1.590" -3.4cc
WISK157A3* 3.810" 3.126" 5.700" 8.353" 1.090" -3.4cc
WISK157A4* 3.820" 3.126" 5.700" 8.353" 1.090" -3.4cc
* Pistons are engineered for use with small block Chevy 5.700" connect-
ing rods.
CHEVY SPIN-ON OIL FILTER
CONVERSION KIT WIX24061
Convert 1956-67 Chevy V-8's from OEM canister
type to spin-on oil filter. Includes base, gasket,
RACING OIL FILTERS mounting bolts and instructions.
Wix racing oil filters use “glass enhanced”
cellulose media, to capture particles as small OIL FILTER ADAPTERS
as 10-12 microns, removing up to 94% more When exhaust header-to-oil filter clearance is an issue, specialized adapters
dirt than traditional filters. Many filters include built-in bypasses to maintain oil convert engine mounted filter to a remote mounted base. Adapters include 1/2"
pressure even under heavily clogged conditions. NPT female inlet and outlet ports. Oil lines must be purchased separately.
Thread By-Pass Part No. Description
Part No. Application Height Dia. Size Rate Flow Oil Filter Adapter, 3/4"-16
WIX51060R Chevy 5.170" 3.600" 13/16"-16 None 28 GPM WIX24730 Threads (Ford/Chrysler)
WIX51061R Late GM 5.178" 3.660" 13/16"-16 None 28 GPM Oil Filter Adapter,
WIX51069R Chevy 4.330" 3.600" 13/16"-16 None 28 GPM WIX24734 13/16"-16 Threads (GM)
WIX51222R Remote Mount 6.210" 4.600" 1-1/2"-12 18-22 PSI 28 GPM
WIX51515R Chrysler/Ford 5.170" 3.600" 3/4"-16 8-11 PSI 28 GPM REMOTE MOUNT OIL FILTER
WIX51794R Chevy 7.820" 3.600" 13/16"-16 None 28 GPM MOUNTING BASE
WIX57003R Remote Mount 6.210" 4.600" 1-1/2"-12 18-22 PSI 30 GPM Used with an oil filter adapter, remote mounted base
WIX57007R Remote Mount 5.900" 4.200" 1-1/2"-16 18-22 PSI 30 GPM can filter engine oil, transmission fluid, etc. Base has
three mounting holes, dual 1/2" NPT inlet and outlet
RACING AIR FILTERS ports, and two 1/2" NPT plugs for blocking off unused ports.
Racing air filter elements flow over 1,000 CFM without compromising filtering Part No. Description
qualities. The Wix racing air filters remove dirt, debris and other contaminants Remote Mounted Base,
before they enter the engine, for extended piston ring life. Filters are offered for WIX24764 Accepts 3/4"-16 Filters (Ford/Chrysler)
asphalt or dirt racing. WIX24766 Remote Mounting Base, Accepts 13/16"-16 Filters (GM)
Part No. Description
Asphalt Racing Air Filters INLINE FUEL FILTER WIX24003
WIX46945R 14" Dia. x 3" Tall High flow, inline fuel filter assembly is 2-3/16"
WIX46926R 14" Dia. x 3.25" Tall O.D. x 11" long and includes a replaceable 7
WIX46948R 14" Dia. x 3.50" Tall micron paper element. Compatible with gasoline or alcohol, filter has 3/4" NPT
WIX46927R 14" Dia. x 3.75" Tall WIX46945R inlet and outlet ports and a flow rate of 12 GPM.
WIX46944R 14" Dia. x 4" Tall Part No. Description
WIX46974R 16" Dia. x 3" Tall WIX24004 Replacement Element
WIX46949R 16" Dia. x 3.5" Tall REPLACEMENT FUEL FILTER
WIX46940R 16" Dia. x 4" Tall
Dirt Racing Air Filters WIX33900R
WIX42096R 14" Dia. x 4" Tall Paper element is a direct replacement for the Fram HPGC1.
