Page 698 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

REUSABLE STEEL HOSE ENDS FOR POWER STEERING HOSE ADAPTERS
BRAKE, CLUTCH OR INSTRUMENT LINES STEEL INVERTED FLARE ADAPTER
Maximum high pressure hose ends are engineered for XRP PTFE hose and
Thread
may be used for brake, clutch and instrument lines. Part No. Inv. Flare Male JIC
Size
XRP790126 1/2"-20 -6
XRP790586 5/8"-18 -6
XRP791166 11/16"-18 -6

Size Straight 45° Tube 90° Tube ALUMINUM BUMP TUBE ADAPTERS
-3AN XRP600003 XRP604503 XRP609003 Thread
-4AN XRP600004 – XRP609004 Part No. With O-Ring Size
XRP491615 M16 x 1.5 -6
ASSEMBLED STAINLESS XRP491815 M18 x 1.5 -6
STEEL BRAIDED PTFE HOSE XRP791615 M16 x 1.5 -6
WITH FITTINGS XRP791815 M18 x 1.5 -6
Ready to install lines have crimped and swaged
ends for use in brake, clutch or instrument systems.
Choice of straight fittings on both ends, or straight on STEEL REUSABLE 90° ADAPTER
one end and 90° on the other, in a variety of lengths. Thread
Part No. Inv. Flare Size
90° to Straight
Length Straight to Straight -3AN Straight to Straight -4AN -3AN XRP509006 9/16"-18 -6
9" XRP630009 – –
12" XRP630012 XRP640012 XRP639012 STEEL METRIC ADAPTERS
15" XRP630015 XRP640015 – Thread
18" XRP630018 XRP640018 – Part No. With O-Ring Size
20" XRP630020 – –
21" XRP630021 – – DRY SUMP OIL SYSTEM FITTINGS
24" XRP630024 XRP640024 XRP639024
27" XRP630027 – – -12 MALE FLARE TO
30" XRP630030 – – -12 ORB FITTING WITH
33" XRP630033 – – FILTER SCREEN
36" XRP630036 XRP640036 XRP639036
42" XRP630042 – – Part No. Description
45" XRP630045 – – XRP980012FS Straight With Coarse, -16AN Mesh Screen
50" XRP630050 XRP640050 XRP639050 XRP98912FS 90° With Coarse, -16AN Mesh Screen
72" – XRP640072 –
SPECIAL ALUMINUM
STEEL BRAKE LINE ADAPTERS AN MALE TO PIPE ADAPTER
Part No. Description Part No. Description
Male Flare Seal Adapters XRP981687 -8AN To 1/4" Male NPT, Extended, 2.1" Long
XRP402703 3/8"-24 Inverted Flare To -3
XRP402903 7/16"-20 Inverted Flare To -3AN WELD BUNGS
XRP420104 M10 x 1.0 Inverted Flare To -4
Crush Washer Seal Adapters -
One Pair
XRP422534 M10 x 1.25 To -4
Female
Female
Male
XRP425033 M10 x 1.5 To -3 Size Weld Bung ORB Weld Bung Pipe Pipe Weld Bung
Size
Female To Male -4 XRP987104 XRP997104 1/8" XRP996701
Bulkhead Adapter -6 XRP987106 XRP997106 1/4" XRP996702
XRP410103 M10 x 1.0 Inverted Flare To -3 -8 XRP987108 XRP997108 3/8" XRP996703
XRP410104 M10 x 1.0 Inverted Flare To -4 -10 XRP987110 XRP997110 1/2" XRP996704
Flare To 1/8" Pipe -12 XRP987112 XRP997112 3/4" XRP996706
XRP481603 Short 1/8" NPT To -3 -16 XRP987116 XRP997116 Female Pipe
XRP481674 Long 1/8" NPT To -4 -20 XRP987120 XRP997120 Pipe Size Recessed Flange
Female To Male Adapters 1/8" XRP996801
XRP402403 7/16"-24 Inverted Flare To -3
XRP402503 3/8"-24 Short Inverted Flare To -3
Banjo Fittings
XRP403803 Short Neck M10/3/8" To -3 Male
Adapters
For Mopar Master Cylinder
XRP490803 1/2"-20 To -3AN
XRP490903 9/16"-20 To -3AN
XRP490933 9/16"-18 To -3AN
