COOLING Aluminum Tank Radiators Plastic Tank Radiators

Uniquely designed plastic tank radiators with aluminum
Excellent quality at an affordable price. Filler necks ar e
machined, not stamped, and tanks are furnace brazed,
aluminum tank radiators when filled with coolant. These
not epoxied, eliminating two prime sources of leakage.
performance radiators also provide 6% better cooling
The lightweight 1" tubes, arranged in two rows, offer core offer over a 22% gross weight savings to comparable
outstanding cooling in race cars, off-road vehicles and than aluminum tank radiators. Tanks are fastened to the
street machines. core with multi-clamps and an o-ring gasket, a process
similar in design to many of today’s high performance late
Single Pass model muscle cars. Corrosion resistant tanks have molded
1-1/2" inlets and 1-3/4" outlets in 1-1/2" inlet and 1-3/4" beaded hose outlets. Widths are
have beaded hose fittings. overall including tanks.
• Lightweight Design
Core WxH Overall
GM • 22% Weight Savings
ALL30010 17" x 18" 22" x 19"
ALL30011 19" x 18" 24" x 19" ALL30012 • 6% Better Cooling
ALL30012 21" x 18" 26" x 19"
ALL30014 23" x 18" 28" x 19" • Corrosion Resistant
ALL30016 26" x 18" 31" x 19"
ALL30042 23" x 15" 28" x 16"
Ford Single Pass
ALL30020 17" x 18" 22" x 19"
ALL30021 19" x 18" 24" x 19" Core WxH Overall
ALL30022 21" x 18" 26" x 19" GM
ALL30024 23" x 18" 28" x 19" ALL30022 ALL30050 17" x 18" 22" x 19" ALL30052
ALL30026 26" x 18" 31" x 19" ALL30051 19" x 18" 24" x 19"
ALL30043 23" x 15" 28" x 16" ALL30052 21" x 18" 26" x 19"
ALL30053 23" x 18" 28" x 19"
Dual Pass ALL30054 26" x 18" 31" x 19"
Ford
Dual pass radiators circulate ALL30320 17" x 18" 22" x 19"
coolant across the top half of ALL30321 19" x 18" 24" x 19"
the radiator, then back across ALL30322 21" x 18" 26" x 19"
the bottom half, allowing up to ALL30324 23" x 18" 28" x 19"
twice the heat dissipation. 1-3/4" outlet. The ALL30035 ALL30326 26" x 18" 31" x 19"
universal inlet design accepts 1-1/2" standard hose, ALL30322
1-3/4" hose, -16 or -20AN fittings (sold separately).
Core WxH Overall
ALL30033 19" x 18" 24" x 19" Dual Pass
ALL30035 21" x 18" 26" x 19" GM Core WxH Overall
ALL30036 23" x 18" 28" x 19" ALL30056 19" x 18" 24" x 19"
ALL30037 26" x 18" 31" x 19"
ALL30057 21" x 18" 26" x 19"
ALL30058 23" x 18" 28" x 19"
Triple Pass ALL30059 26" x 18" 31" x 19"
Triple pass radiators circulate
coolant across the top portion
of the radiator, back across
the mid-section and through TECH TIP
the bottom allowing maximum Radiators with plastic tanks are designed to use radiator
heat dissipation. Standard 1-3/4" caps rated at 22 lbs. or less.
outlet and a universal inlet designed to accept ALL30046
1-1/2" standard hose, 1-3/4" hose, -16 or -20AN fittings Radiators with aluminum tanks are designed to use
(sold separately). radiator caps rated at 25 lbs. or less.
Core WxH Overall
ALL30045 19" x 18" 24" x 19"
ALL30046 21" x 18" 26" x 19" Radiator Inlet Fittings
ALL30047 23" x 18" 28" x 19" ALL30038 ..... 1-1/2" Hose Fitting
ALL30048 26" x 18" 31" x 19" ALL30041 ..... 1-3/4" Hose Fitting* ALL30038 ALL30041
ALL30039 ..... -16AN Fitting
ALL30040 .... -20AN Fitting
*Use with lower radiator hose

ALL30039 ALL30040
