Page 98 - 2018 Allstar Performance Parts and Equipment Catalog

ENGINE Caster Wheel Kits Aluminum Sprint Motor Plates

Hard rubber wheel kits may be
mounted to Allstar engine cradles
ALL10130 thru ALL10159. Kits are also ALL38118 ALL38119
available with locking wheels, ideal
for storing spare engines in trailer. ALL38128 ALL38130
Standard duty kits feature 3/8" studs
and heavy duty models use 1/2"
studs. Four wheels per kit.
ALL10162...... Std. Duty 3" Dia. Kit Front motor plates for SB Chevy are
ALL10163 ..... Std. Duty 3" Dia. With Locking Kit offered in one- and two-piece
ALL10164 ..... Heavy Duty 3" Dia. Kit designs. One-piece versions mount
ALL10165...... Heavy Duty 3" Dia. With Locking Kit using the lower front mounting
ALL10166 ..... Heavy Duty 5" Dia. Kit holes. Two-piece sets use the
lower front mount holes and
the water pump mounting holes. All plates have ALL38145
Chevy Economy 19-1/2" center-to-center chassis mounting holes. ALL38128
and ALL38145 plates come with bushings to allow for
Engine Cradle engine flex and help with weight transfer.
ALL10171
Part No. Description Finish Thickness
Cradle is great for storing or ALL38118 1-Piece Solid Plate Plain 3/8"
transporting engines safely. ALL38119 1-Piece Solid Plate Black 3/8"
Designed to fit small and ALL38128 1-Piece Plate With Bushings* Black 3/8"
big block Chevrolet engines, Does Not ALL38145 2-Piece Plate With Bushings † Black 3/8"
cradle is fully welded from 1" square Accept Wheel Kits ALL38130 Universal Mount Plain 1/4"
tubing and powder coated black. *Has built-in mount for Saldana tank mount bracket OTMB-1.
†Designed to work with ALL36092 and ALL36093 tank mounts.
Sprint Engine Cradle
SB Chevy Two-Piece Engine Stand ALL10159
ALL10157 Cradle bolts to
Two-piece engine stand most stock type and
constructed from 1" x 2" aftermarket SB Chevy
steel tubing is specially blocks, including
designed to clear most narrow pattern light-
oversized dry sump weight, and standard
oil pans with up to a bell housing bolt patterns. Slotted front
9" deep sump. Stand includes six mounts accept most frame width engine mounts.
3/8" x 1" grade 5 bolts and accepts Provisions for standard wheel kits are positioned to
wheel kits with 3/8" studs. support complete engines with attached radiators.

Bellhousing Dowel Pins
Motor Plates Steel dowel pins are approximately
Motor plates are used 1/2" longer than stock pins and are
to replace the front required when running an engine mid-
motor mounts allowing ALL38120 plate, rear motor mounts or an aftermarket ALL38152
relocation of the engine in the chassis, including bellhousing. These extended length pins also help with
lowering or when moving the engine back in the chassis. alignment when installing an engine. Pins fit most GM
Plates prevent engine movement and reinforce the front blocks and are sold in pairs.
suspension for better handling and increased reaction times. ALL38150 ..... Solid Pins
Fabricated from 1/4" thick 6061-T6 aluminum, motor plates are ALL38152 ..... Hollow Pins
often trimmed to fit the chassis or frame mounts. Plates are
machined for a perfect fit to mount between the water pump Engine Cover ALL26234
and engine block. Water-repellent cover
ALL38120 ..... SB Chevy 10" x 36" with bottom draw NEW!
ALL38124 ..... BB Chevy 12" x 36" string is perfect for storage or
transportation. 32" long x
23" wide x 28" tall.

96 www.allstarperformance.com
