Chief Architect X10 Reference Manual

• Keyboard-Tilt Camera lets you use the
Arrow keys to tilt the camera up, down, Note: Although the Arrow keys are set to
or side to side to change the focal point. move active cameras by default, you can cre-
The camera’s direction changes, but its ate custom hotkeys for these commands if
position does not. you prefer. See “Hotkeys” on page 148.

Move Camera Tools

Select 3D> Move Camera in a 3D These tools use the Incremental Move
view to access these tools. These tools Distance set in the active 3D view’s Camera
change the active camera’s position, but not Specification dialog.
its direction and are not available in
Orthographic views.

Hotkey Description

F Move Camera Forward moves the camera and its focal point forward.

B Move Camera Back moves the camera and the focal point back.

L Move Camera Left moves the camera and the focal point to the left in
a line perpendicular to the line of sight.

R Move Camera Right moves the camera and the focal point to the right
in a line perpendicular to the line of sight.

U Move Camera Up moves the camera and the focal point up.

D Move Camera Down moves the camera and the focal point down.

Orbit Camera Tools

Select 3D> Orbit Camera in a 3D the active view’s Camera Specification
view to access these tools. Orbiting dialog.
the camera rotates it about the focal point These tools are not available in , Back
using the Incremental Rotate Angle set in
Clipped Cross Section, or Wall Elevation
views.

1064
