Chief Architect X10 Reference Manual

Hotkey Description

Turn Camera Left turns the camera to the left while staying in the
same location.

Turn Camera Right turns the camera to the right while staying in the
same location.

View Direction Tools

The View Direction Tools allow you
to view the model from a specific Description
direction in a camera view, overview, or
cross section/elevation view. While one of Top View creates a top view of
these views is active, select 3D> View the model.
Direction to access these tools. Bottom View creates a bottom
view of the model.

Left Side View create a left side
Description view of the model.

Front View creates a front view Right Side View create a right
of the model. side view of the model.
Back View creates a back view Restore Original View restores
of the model. the original view position.

Editing 3D Views
In addition to its position and direction, there position, appearance, and other attributes.
are other ways to modify a 3D view. See “Camera Specification Dialog” on page
1075.
In the Specification Dialog

You can make adjustments to a Tile a 3D view and the floor plan view
camera in the Camera Specification and use the camera movement tools to
dialog. This dialog is particularly helpful for see how they affect the camera. See “Tiling
Views” on page 158.
making fine adjustments to the camera’s

1066
