P. 1071

Working in 3D



                               All moving or resizing is in the plane of the   Material dialog for that material. See “Adjust
                               handle surface. You cannot  move an object   Material Definition” on page 1021.
                               directly towards or away from the camera,    Select 3D> Material Painter to apply
                               for example, because that surface plane      materials to surfaces in the view using
                               cannot be seen in the view.
                                                                       the Material Painter Tools. See “The Material
                               By default, object movement is restricted to   Painter” on page 1014.
                               one inch or 10 mm increments, but this       Select 3D> Material Painter>
                               restriction can be set to custom increments in   Material Eyedropper to apply the
                               the Plan Defaults dialog and toggled off and
                                                                       material on a surface in the view to other
                               on using the Grid Snaps    button. See   surfaces in the view. See “Material
                               “Grid Snaps” on page 172.               Eyedropper” on page 1016.
                               Unrestricted positioning can also be enabled
                               by holding down the Ctrl key while moving           Rebuild 3D
                               or resizing an object. See “Unrestricted     As changes are made to your plan, a
                               Movement” on page 249.
                                                                            3D view automatically updates to
                               Temporary dimension lines display when   reflect any changes visible in the view. If you
                               many objects are selected to help you resize   find that a view is not updating as expected,
                               the object and determine its height. These are   select 3D> Rebuild 3D to rebuild the entire
                               sometimes easier to see when the color is   3D model.
                               toggled off. See “Temporary Dimensions” on
                               page 468.                                     Annotating 3D Views
                               Because cross section/elevation views are   The Dimension Tools, Text Tools, and CAD
                               orthogonal and display objects at their actual   Tools are available in cross section/elevation
                               dimensions, they are sometimes more     views, allowing you to add technical
                               suitable for editing objects than camera   information, call attention to details, and
                               views or overviews. See “Cross Section/  other tasks in these views. See “Detailing
                               Elevation Views” on page 1052.          Cross Section/Elevation Views” on page
                                                                       1055.
                               When several 3D views are open, changes
                               made in the plan automatically rebuild the   You can also add annotation to any other 3D
                               model in all views.  Because of this, it is   view by first making a line-drawn copy of
                               typically faster to make changes to your plan   the view using the CAD Detail from
                               with as few windows open as possible.
                                                                       View    tool. See “CAD Detail from View”
                                                                       on page 334.
                                 Editing Materials in 3D Views
                                     Select 3D> Materials> Adjust             Cross Section Lines
                                     Material Definition, then click on a
                               surface in the 3D view to open the Define   Cross Section Lines are created in cross
                                                                       section views to represent any objects split
                                                                       by the cross section line of the camera. They



                                                                                                      1071
