Road Specification Dialog

Curb Panel

• Check Has Curb if you want the selected The SELECTED ARC panel is available when
road to include a curb. the curved segment of a Straight Road is
• C l i c k Select Curb Profile to apply a dif- selected. See “Arc Panel” on page 309.
ferent curb profile to the selected road.
Spline Panel
• C l i c k Default Curb Profile to use the
default curb profile. The SPLINE panel is available when a Spline
• Enter a Width value for the curb. Road is selected. Specify the angle between
the line segments used to draw the spline.
• Enter a Height value for the curb. For more information, see “Spline Panel” on
• Check Cut Curb for Driveways and page 314.
Sidewalks to cut the curb for driveways
and sidewalks. Line Style Panel

Polyline Panel This panel is the same as the LINE STYLE
panel in many other specification dialogs.
The POLYLINE panel states the length of the See “Line Style Panel” on page 301.
road’s Perimeter, its Area and its Volume.
Not available in the Road Defaults dialog. Fill Style Panel
For more information, see “Polyline Panel”
on page 314. The settings on the FILL STYLE panel affect
the appearance of the selected object in floor
Selected Line/Arc Panel plan view. For information about these
settings, see “Fill Style Panel” on page 315.
The SELECTED LINE panel is available when
a Straight Road is selected. For more Materials Panel
information, see “Line Panel” on page 300.
The settings on the MATERIALS panel affect
the appearance of the selected object in 3D
