views. For information about these settings, Label Panel
see “Materials Panel” on page 1017.
Road labels displays in floor plan and cross
The material selected here is not calculated section/elevation views when the “Terrain
in the Materials List. See “Materials Lists” Labels” layer is turned on and use the Text
on page 1263. Style assigned to that layer. See “Terrain and
Road Labels” on page 1214.
For more information, see “Label Panel” on
page 682.

Median Specification Dialog

Select a median and click the Open The settings in this dialog are similar to those
Object edit button to open the Median in the Road Specification dialog.
Specification dialog.

Driveway Specification Dialog

Select a driveway and click the Open The settings in this dialog are also found in
Object edit button to display the the Driveway Defaults dialog and are similar
Driveway Specification dialog. to those in the Road Specification dialog.
See “Road Specification Dialog” on page
1245.

Road Marking Specification Dialog

Select a Road Marking or Road Stripe General Panel
and click the Open Object edit button
to open the Road Marking Specification The GENERAL panel is only available for
dialog. Road Stripes.

The settings in this dialog are also found in
the Road Marking Defaults dialog and are
similar to those in the Road Specification
dialog. See “Road Specification Dialog” on
page 1245.
