Road Marking Specification Dialog

Enter a Width value for the selected Road Fill Style Panel
Stripe.
The settings on the FILL STYLE panel affect
Polyline Panel the appearance of the selected object in floor
plan view. For information about these
The POLYLINE panel states the length of the settings, see “Fill Style Panel” on page 315.
road marking’s Perimeter, its Area, and its
Volume. Not available in the Road Marking Materials Panel
Defaults dialog. For more information, see
“Polyline Panel” on page 314. The settings on the MATERIALS panel affect
the appearance of the selected object in 3D
Selected Line/Arc Panel views. For information about these settings,
see “Materials Panel” on page 1017.
The SELECTED LINE panel is available when The material selected here is not calculated
the straight segment of a road marking is in the Materials List. See “Materials Lists”
selected. See “Line Panel” on page 300.
on page 1263.
The SELECTED ARC panel is available when
the curved segment of a road marking is Label Panel
selected. See “Arc Panel” on page 309.
Road Marking labels displays in floor plan
Line Style Panel view when the “Terrain Labels” layer is
turned on and use the Text Style assigned to
This panel is the same as the LINE STYLE that layer. See “Terrain and Road Labels” on
panel in many other specification dialogs and page 1214.
affects the appearance of the selected object For more information, see “Label Panel” on
in floor plan view. See “Line Style Panel” on page 682.
page 301.
