The Layout Tools

are referenced by the layout. See sent to layout to be edited individually. See
“Referenced Plan Files Dialog” on page “Editing Layout Lines” on page 1299.
1307.
Managing Layout Pages
Editing Layout Views
Select Tools> Layout> Edit Page
A selected layout view can be edited much Information to open the Layout
like other box-based objects. See “Editing Page Information dialog. See “Layout Page
Box-Based Objects” on page 236. In Information” on page 1311.
addition, a variety of edit tools allow you to Select Tools> Layout> Insert Page
control the appearance of each view.
Before to add a new layout page,
Select a layout view and click the moving the current page and all following
Open View edit button to open the pages up one page, as long as there is nothing
view that was originally sent to layout. This on page 1000.
tool is only available for dynamic views. See Select Tools> Layout> Insert Page
“Editing Dynamic Views” on page 1298.
After to add a new layout page,
Select a layout view and click the leaving the current page where it is but
Rescale Layout edit button to open moving all following pages up one page, as
the Change Scale dialog and apply a long as there is nothing on page 1000.
different scale. See “Rescaling Views” on Select Tools> Layout> Delete Page
page 1299.
to delete the current layout page,
Select a layout view and click the moving all following pages down one page,
Relink File edit button to open the as long as nothing is on the current page.
Choose Layout File Reference dialog and Select Tools> Layout> Exchange
relink the selected layout view. See With Next Page to switch the current
“Relinking Layout Views” on page 1308.
layout page with the following page. Not
Select a layout view and click the available on Layout Page 1000.
Layout Box Layers edit button to
open the Layer Display Options dialog for Select Tools> Layout> Exchange
With Previous Page to switch the
the selected view. See “Displaying Layout current layout page with the page preceding
Views” on page 1296.
it. Not available on Layout Page 0.

Note: You can also modify the layers of the
layout file itself. See “Layout Page Display You can also specify the page that an
Options” on page 1286. object or group of objects displays on
in its specification dialog. See “Line Style
Panel” on page 301.
Select Tools> Layout> Edit Layout
to allow the lines of a Vector View

1287
