Chief Architect X10 Reference Manual

• Specify the Date that the revision was your Designer Information by default.
made. The program populates this field See “Designer Information” on page 77.
with the current date automatically. • Specify a Description of the revision.
• Specify who the revision was Revised • Check Include in Revision Table to
By. The program populates this field with include this revision in a Layout Table for
the selected page.

Layout Page and Revision Tables

Title, revision, and other information can be If you place a Layout Page Table on a Page
added to each layout page and used to create Template, it will display on every page in the
tables of contents and revision schedules. current layout that uses that template and will
list all pages that have data and are set to be
Layout Tables are similar to schedules and included in Layout Page Tables.
can be edited much the same way that
schedules can. See “Editing Schedules” on
page 669. Revision Tables
Select Tools> Layout> Layout
Layout Page Tables Revision Table, then click on a layout
page to place a Layout Revision Table that
Select Tools> Layout> Layout Page that location. Layout Revision Tables list all
Table, then click on a layout page to
place a Layout Page Table that that location. revisions associated with the current page.
Layout Page Tables list all pages in the Unlike Layout Page Tables, Layout Revision
current file that have Layout Page Tables are page-specific. If you place a
Information specified, are set to be included Layout Revision Table on a Page Template, it
in Layout Page Tables, and have data on will display on every page that uses that
them. See “Layout Page Information” on template, but it will only list revisions
page 1311. associated with the current page. See
“Layout Page Templates” on page 1311.

Printing Layout Files

Printing layout files is similar to file. See “Drawing Sheet Setup Dialog” on
printing a view in a plan file. Select page 1324.
File> Print> Print to open the Print dialog. If a page does not have any data on it, it will
See “Print View Dialog” on page 1336.
not print. Only pages with one or more views
As in plan views, printing options for layouts sent to them or Text, CAD, or Dimensions
are set in the Drawing Sheet Setup dialog. drawn on them are printed.
These options apply to all pages of the layout

1314
