Layout Page Information

• Click the New button to open the Layout
If you type a pound sign # in the Label Revision Specification dialog and add a
field, it will be replaced by the current new revision to the selected page.
layout page number on the layout sheet. See
“Layout Page Numbering” on page 1310. • Click the Edit button to open the Layout
Revision Specification dialog and edit
• Specify the selected page’s Title. the selected revision.
• Specify the selected page’s Description. • Click the Delete button to remove the
selected revision from the table.
• Specify the selected page’s Comments.
• Click the Move Up or Move Down but-
• Check Include in Layout Table to ton to adjust the position of the selected
include the above information about the revision in the table accordingly.
selected page in a Layout Table. If Use as
Page Template is checked, this box will
be unchecked automatically. Revision Specification Dialog

2 The Page Template Options let you Select Tools> Layout> Add Layout
Revision to open the Revision
associate the selected layout page with
a template, or specify it as a template. See Specification dialog. You can also click the
“Layout Page Templates” on page 1311. New or Edit button in the Layout Page
Information dialog to open this dialog.
• Check Use as Page Template to specify
the selected page as a template that can
be assigned to other pages, but not
printed. This box cannot be unchecked if
the current page is the Page Template
assigned to other pages.
• Assign a Page Template to the selected
page by choosing one from the drop-
down list. Not available when Use as
Page Template is checked.

3 The Page Revisions settings let you
manage the revisions associated with
the selected page. Revisions can be shown in
a Revision Table or added to text using a 1 Revised Pages - Specify which pages
macro. See “Revision Tables” on page 1314. the selected revision applies to. Only
• A table listing any revisions associated available when a new revision is being
with the selected page displays for refer- created.
ence. Click on a line item in the table to Revision Information -
select it. 2
• Specify the revision’s Label.
