Chief Architect X10 Reference Manual

Relinking Layout Views to link to and click Open. See “Opening and
Importing Files” on page 63.
You can change the file that a dynamic
layout view is linked to by selecting In the Windows version of the software, this
the view and clicking the Relink File edit dialog opens to the linked file’s specified
button to open the Choose Layout File directory and populates the Filename field
Reference dialog. This dialog is a typical with that file’s name.
Open File dialog: select the file that you want If you want to relink all references to this
file, use the Referenced Plan Files dialog.

Missing Layer Sets
The layer set associated with each view in a layer set used by a layout view. See
layout is saved with the plan file from which “Opening and Importing Files” on page 63.
the view was sent. Just as it is important to If a layer set used by a layout view cannot be
not move, rename, or delete the plan file, it is found when the layout is opened, the
important that you not rename or delete a
Missing Layer Set dialog will display.

1 The Layout Box Information 2 The Layer Sets options allow you to
describes the layout view that is replace the missing layer set.
missing a layer set, indicating: • The name of the Missing Layer Set dis-
• The Layout Page where the view in plays for reference.
question is located; • Select a replacement layer set from the
• View Information, which describes the Available Layer Sets drop-down list.
contents of the view in question, • Click the Define button to open the
• The Plan Filename of the plan file that Layout Page Display Options dialog,
the layer set is missing from. where you can make changes to the
selected layer set.

1308
