Layout Box Specification Dialog

• Uncheck Show Color to turn color off in Reference Floor draws last and appears in
the selected view. See “Color On/Off” on front of the objects on the current floor.
page 202. • Use XOR Drawing changes the color of
3 Check Show Reference Floor to lines in the Reference Floor that are
include the Reference Floor in the drawn on top of other lines. Lines with
selected view and enable the settings below. identical properties do not display. When
See “Reference Floor Display” on page 722. unchecked, the Reference Floor color
does not change, and identical lines are
• Select which floor to use as the Refer- not suppressed.
ence Floor from the drop-down list.
• Use Object Settings displays the line and
• Select the Reference Layer Set to use fill styles of objects in the Reference
from the drop-down list.
Floor that aren’t using their default line
• Check Draw Reference Floor First to and fill styles. When this is unchecked,
draw the Reference Floor before the objects display according to their layer
drawing the objects on the floor shown in settings in the Reference Floor Layer Set.
the view. When this is unchecked, the

Camera View Panel
The CAMERA VIEW panel is only available Lines view. See “Dynamic Views” on page
when the selected view is a Live View or Plot 1293.

1 The Camera View Options are views, and overviews sent to layout. See
available for Dynamic and Semi- “Keeping Layout Views Current” on page
Dynamic cross section/elevation, camera 1293.

1303
