Chief Architect X10 Reference Manual

1 Specify the Number Height for The settings that follow are only available
Dimensions in the selected view. Type when the layout view is not linked to a saved
a (D) to use the default height for the selected Plan View. See “Plan Views” on page 154.
view. See “Dynamic Defaults” on page 88. • Select the Current Floor shown in the
This setting is only available for views sent layout view from the drop-down list.
to layout from floor plan view and CAD • Select the Current Annotation Set from
Details. It affects the size of dimension the drop-down list. The options available
numbers in the layout view but not in the are limited to the Annotation Sets saved
original view in the plan file. in the view’s plan file.
The Current Annotation Set does not
The Number Height setting is included affect the layout view’s appearance, but
for legacy files and is not the recom- will determine what Annotation Set is
mended method of specifying dimension active if you use the Open View e d i t
size. See “Dimension Labels” on page 472.
tool to return to the original view. See
“Annotation Sets” on page 1305.
Specify the floor and Annotation Set
2
associated with the selected view.
• Select the Linked Saved Plan View Note: “Active Defaults” will be included in the
shown in the layout view from the drop- Current Annotation Set list if Make Copy of
Active Layer Set was checked when the view
down list. was sent to layout, or if Active Defaults were
in use when it was sent to layout.

1302
