Layout Page Information

There is also a selection of additional text • Title Block. See “Text, Callouts, and
macros that can be used to insert dynamic Markers” on page 487.
page numbering information: • Borders. See “CAD Objects” on page
287.
Macro • Text Macros. See“Text Macros” on page
%page% Layout Page Number - 522.
States the absolute page • Imported images. See “Images” on page
number of the current layout 1140.
page.
%page.print% Printed Page Number -
States the printed page num- Note: The printable area varies from printer to
ber of the current page. printer. For best results, inset layout borders
Blank pages are not 1/2" to 3/4" from the paper edge.
included in this count.
%numpages% Number of Printed Pages - You can assign a Page Template to any
States the total number of layout page, or specify any page as a Page
printed pages in the layout. Template, in the Layout Page Information
%lastpage% Last Used Layout Page - dialog.
States the absolute page
number of the last printed For more information about creating a title
page. block and border for your layout template,
Layout Page Templates see “Creating a Border and Title Block” on
page 514 of the User’s Guide.
Layout Page Templates allow you to create a
title block and border in one place and then Layout Page Zero
assign them for use on any other layout pages
that you wish. Multiple Page Templates can In Chief Architect X5 and prior, Layout Page
be created in the same layout file. Note that if Zero was the only available Page Template.
a layout page is specified as a Page Template, In Version X10, it functions in much the
it will not print as part of a print range. Page same way by default: it is specified as a Page
Templates can be printed as the Current Template with the title “Default Page
Sheet, however. See “Print View Dialog” on Template”, and it is assigned to all pages.
page 1336. Because of its special purpose, page zero
Add anything to a Page Template that you cannot be deleted.
want on some or all of your printed layout
pages, such as:

Layout Page Information

The Edit Page Information tool dialog, which you can use to add title,
opens the Layout Page Information revision, and other information to the current

1311
