Chief Architect X10 Reference Manual

unchecked, the ceiling height and finish • Specify the Height Raised, which is the
material within the window is the same as measured from the floor height of the
that for the adjacent room. adjacent room.
• Specify the Height Lowered, which is
measured from the ceiling height of the Note: If the Height Raised is 0”, Has Raised
adjacent room. Floor will become unchecked when you click
OK.

Note: If the Height Lowered is 0”, Has Low- • Check Use Floor Finish to measure the
ered Ceiling will become unchecked when Height Raised distance from the surface
you click OK.
of the floor finish. When unchecked, as it
• Specify the Finish Thickness, which is is by default, this height is measured
the thickness of the ceiling’s finish mate- from the subfloor.
rial. • Specify the Finish Thickness, which is
• Specify the Structure Thickness, which the thickness of the floor’s finish mate-
is the thickness of the ceiling’s structural rial.
layer. • Specify the Structure Thickness, which
is the thickness of the floor’s structural
5 Specify the height and structure of the layer.
Floor within the selected window.
• Check Has Raised Floor to enable the 6 Check Include in Schedule to include
settings that follow. When this is the selected window(s) in Window
unchecked, the floor height and material Schedules. See “The Schedule Tools” on
within the window is the same as that for page 668.
the adjacent room.

602
