Chief Architect X10 Reference Manual

“Solid Concrete” is selected from the Type
None Flat to Outside drop-down list.
• Specify the Size Number for both Rebar
and Stirrups.
• Specify the Count, or number of bars, for
both Rebar and Stirrups.
Flat to Inside
• Specify the length of Rebar Extensions.
4 Length and Angle - Lock the point • Specify the distance that Stirrups Over-
about which you want like the selected lap.
object to resize and/or rotate, then specify its
exact length and angle. See “Editing Rafter Tails Panel
Framing” on page 865.
The RAFTER TAILS panel is only available for
• Specify the Length of the framing object.
Rafter length is measured along the top of Rafters, Subfascia, and Roof Beams. The
the rafter, and so is greater than the length settings here allow you to specify a rafter tail
measured in floor plan view. Not avail- profile for exposed end rafter ends under roof
able for Posts. eaves. See “Rafter Tails Panel” on page 787.
• Width 1 and 2 - Specify the Post width in Line Style Panel
each dimension. When a Round Post is
specified, Width 1 refers to its diameter The settings on the LINE STYLE panel affect
and Width 2 is not available. the selected object’s line style, its bumping
behaviors, and its drawing order. For more
• Specify the Angle of the framing object in
floor plan view. Changing this rotates the information about the settings on this panel,
object about the location specified by the see “Line Style Panel” on page 301.
radio buttons described below.
Fill Style Panel
• Select Lock Center to resize or rotate the
object about its center point. The settings on the FILL STYLE panel affect
the selected object’s appearance in floor plan
• Select Lock Start to resize or rotate the
object about the location from which you view. For information about these settings,
started drawing the framing object. see “Fill Style Panel” on page 315.
• Select Lock End to resize or rotate the Materials Panel
object about the location where you
stopped drawing it. The default materials on this panel are set in
the Build Framing dialog. If you change the
5 Specify the Rebar and Stirrups for selected object’s framing Type, the material
concrete Posts and Beams. The Rebar here may update - unless you have specified
and Stirrup settings are only available when a non-default material. For information about
the selected object is a Post or Beam and
the settings on this panel, see “Materials
Panel” on page 1017.

872
