Framing Schedules

Label Panel have Wall Detail Position and Orientation
settings.
Framing labels can display in floor plan view
and cross section/elevation views when the For more information about the settings on
“Framing, Labels” layer is turned on and use this panel, see “Label Panel” on page 682.
the Text Style assigned to that layer. See
“Text Styles” on page 519. Note: If a framing member is listed in a
schedule using callout labels, the settings
Automatically generated wall framing can here are overridden and the schedule label is
also display in Wall Detail views. When used instead.
accessed from a Wall Detail, this panel will

Framing Schedules

The Framing Schedule tool allows Framing Schedule. For all other Structure
you to produce customizable framing Types, fractional inches are used.
schedules as well as framing labels that Framing schedules created in Wall
display schedule numbers. See “Schedules
and Object Labels” on page 667. Detail views use a special Only Include
Objects from this Detail setting and a
Schedules of particular types of framing can selection of Objects to Include that report
be created by controlling which Objects to only wall framing members present in the
Include in the schedule. For example, a current view. See “In Wall Detail Views” on
Deck Framing Schedule can be created by page 864.
including “Deck” Objects while excluding
all other Object types. See “General Panel” If placed into a Truss Detail, a framing
on page 676. schedule’s Objects to Include will be
restricted to floor, ceiling, and roof trusses.
In plans using US Units, when a board’s Only Include Objects from this Detail is
Structure Type is “Lumber”, its nominal size also used. See “Truss Details” on page 881.
will be reported in the Nominal column of a
