Place Library Object Button

of the Door Specification dialog, only door
symbols will be listed:

The Select Library Object dialog only
displays categories of items that are related The Select Library Object dialog is similar
to the selected object. For example, if the to the LIBRARY MATERIALS panel of the
dialog is accessed from the GENERAL panel Select Material dialog. See “Select Material
Dialog” on page 1018.

Place Library Object Button

The Place Library Object button can
be added to your toolbar and used for
quick access and placement of frequently
used library items.

If the Place Library Object button has
not yet been assigned a library object, click it
once to open the Library Object Button
Specification dialog.

Double-click a Place Library Object
button that has been assigned a library object
to open the Library Object Button
Specification dialog.

1 Click the Library button to open the
Select Library Object dialog and
assign a library object to the button. If a
library object has already been assigned,
click this button to assign a new library
object. See “Select Library Object Dialog”
on page 940.

2 When a library object has been
selected, type a Button Name in the
text field.

941
