Siding shingles can be applied over either wood or plywood sheathing or over existing board siding.
When installed over sheathing, apply 15-pound asphalt felt between the sheathing and the shingles. If
the surface is irregular, apply horizontal furring strips of 1” x 3” lumber or 1” x 4” lumber. Spacing has to
match the exposed shingle length. Use Figure 6-11 to estimate the furring required for various
exposures per 100 square feet of shingle siding. Leave a gap of 1/8” to 1/4” between shingles to allow for
expansion during wet weather.

Shingle Linear Feet per
Exposure 100 SF of Siding
4” exposure 300 feet
4-1/2” exposure 270 feet
5” exposure 240 feet
5-1/2” exposure 220 feet
6” exposure 200 feet
6-1/2” exposure 180 feet
7” exposure 171 feet
8” exposure 150 feet

Linear feet of furring per 100 square feet of shingle siding
Figure 6-11

Single-course shingles are applied like bevel siding. Each top course laps over the course below with all
joints staggered. See Figure 6-12. Use second-grade shingles (rather than first or third grade) because
only one-half or less of the butt portion is exposed.

Compare the double-course shingles in Figure 6-13. The first grade (No. 1) shingles cover the
undercourse (third grade) shingles. The butt ends of top course shingles should project 1/4” to 1/2”
beyond the butt ends of undercourse shingles. With double coursing, shingle exposure of the top course
can be greater. Figure 6-14 shows recommended exposure distances for shingles.
