2018 National Home Improvement Estimator, All Rights Reserved Page 418

3 conductor, 250' coil BE@.030 LF 0.27 1.31 1.58
14-2-2, per foot BE@.032 LF 1.25 1.40 2.65
14-2-2, 250' coil BE@.032 LF 0.49 1.40 1.89

12 gauge Type NM-B Romex® sheathed indoor cable. Yellow. With full-size ground wire. Rated at
20 amps. Labor is based on installation in a wood-frame building, including boring out and pulling cable
in exposed walls. Add the cost of fishing cable through enclosed walls, when required.
2 conductor, per foot BE@.030 LF 1.26 1.31 2.57
2 conductor, 25' coil BE@.030 LF 0.64 1.31 1.95
2 conductor, 50' coil BE@.030 LF 0.61 1.31 1.92
2 conductor, 100' coil BE@.030 LF 0.45 1.31 1.76
2 conductor, 250' coil BE@.030 LF 0.25 1.31 1.56
3 conductor, per foot BE@.031 LF 1.58 1.35 2.93
3 conductor, 25' coil BE@.031 LF 1.18 1.35 2.53
3 conductor, 50' coil BE@.031 LF 1.11 1.35 2.46
3 conductor, 100' coil BE@.031 LF 0.88 1.35 2.23
3 conductor, 250' coil BE@.031 LF 0.46 1.35 1.82
12-2-2, per foot BE@.032 LF 1.44 1.40 2.84
12-2-2, 250' coil BE@.032 LF 0.73 1.40 2.12

10 gauge Type NM-B Romex® sheathed indoor cable. Orange. With ground. Rated at 30 amps.
Labor is based on installation in a wood-frame building, including boring out and pulling cable in exposed
walls. Add the cost of fishing cable through enclosed walls, when required.
2 conductor, per foot BE@.031 LF 2.73 1.35 4.08
2 conductor, 25' coil BE@.031 LF 1.19 1.35 2.54
2 conductor, 50' coil BE@.031 LF 1.12 1.35 2.47
2 conductor, 100' coil BE@.031 LF 0.97 1.35 2.32
2 conductor, 250' coil BE@.031 LF -- 1.35 1.35
3 conductor, per foot BE@.035 LF 2.87 1.53 4.40
3 conductor, 25' coil BE@.035 LF 1.64 1.53 3.16
3 conductor, 50' coil BE@.035 LF 1.45 1.53 2.98
3 conductor, 100' coil BE@.035 LF 1.09 1.53 2.62
3 conductor, 250' coil BE@.035 LF 0.73 1.53 2.25

8 gauge Type NM-B Romex® sheathed indoor cable. Black. With ground, except where noted.
Rated at 40 amps. Labor is based on installation in a wood-frame building, including boring out and
pulling cable in exposed walls. Add the cost of fishing cable through enclosed walls, when required.
2 conductor, per foot BE@.033 LF 2.02 1.44 3.46
2 conductor, 125' coil BE@.033 LF 0.83 1.44 2.27
3 conductor, no ground, per foot BE@.033 LF 3.26 1.44 4.70
3 conductor, per foot BE@.037 LF 3.17 1.62 4.79
3 conductor, 125' coil BE@.037 LF 1.32 1.62 2.94

6 gauge Type NM-B Romex® sheathed indoor cable. Black. With ground. Rated at 55 amps. Labor
is based on installation in a wood-frame building, including boring out and pulling cable in exposed
walls. Add the cost of fishing cable through enclosed walls when required.
2 conductor, per foot BE@.038 LF 3.09 1.66 4.75
2 conductor, 125' coil BE@.038 LF 1.18 1.66 2.84
3 conductor, per foot BE@.044 LF 4.50 1.92 6.42
3 conductor, 125' reel BE@.044 LF 1.81 1.92 3.73
