Page 530 - 2018 National Home Improvement

2018 National Home Improvement Estimator, All Rights Reserved Page 422

PVC service entrance cap. UL listed. Plus 40 and Plus 80.
3/4" BE@.150 Ea 3.38 6.55 9.93
1" BE@.150 Ea 5.51 6.55 12.06
1-1/4" BE@.300 Ea 6.66 13.09 19.75
1-1/2" BE@.300 Ea 10.20 13.09 23.29
2" BE@.500 Ea 10.71 21.82 32.53

Non-metallic two-gang conduit box, Super Blue, Carlon®. Two-gang hard shell box with captive
nails. Depth 3-1/2", width 4-1/8", length 3-7/8". 8 integral clamps, 4 each side.
35 cubic inch, wood studs BE@.200 Ea 2.08 8.73 10.81
35 cubic inch, steel studs BE@.150 Ea 2.59 6.55 9.13

Non-metallic three-gang conduit box, Super Blue, Carlon®. Three-gang hard shell box with captive
nails. Depth 3-1/2", width 3-3/4", length 5-7/8". 12 integral clamps, 6 each side.
53 cubic inch, wood studs BE@.200 Ea 2.87 8.73 11.60
53 cubic inch, steel studs BE@.150 Ea 2.93 6.55 9.48

Non-metallic ceiling fan box, Carlon®. 4", rated for fans up to 35 pounds. Rated for lighting fixtures
up to 50 pounds. Includes mounting screws.
1/2" deep, 8 cubic inch BE@.300 Ea 3.72 13.09 16.81
2-1/4" deep, 20 cubic inch BE@.300 Ea 5.01 13.09 18.10

Non-metallic old work switch box, Zip-Mount® retainers, Carlon®. For existing construction.
Non-metallic cable clamps. UL listed.
Single gang, 14 cubic inch BE@.200 Ea 1.07 8.73 9.80
Single gang, 20 cubic inch BE@.200 Ea 1.92 8.73 10.65
2 gang, 25 cubic inch BE@.200 Ea 2.35 8.73 11.08
3 gang, 55 cubic inch BE@.200 Ea 2.45 8.73 11.18
4 gang, 68 cubic inch BE@.300 Ea 6.78 13.09 19.87

Non-metallic old work switch box, Zip-Mount® retainers, Carlon®. For existing construction. 4
integral non-metallic cable clamps. 3 Zip-Mount® retainers. 2-3/4" deep. High temperature resistance.
UL listed.
Round BE@.300 Ea 6.78 13.09 19.87

Non-metallic low voltage device mounting bracket, Arlington. Low voltage device; Class 2 only.
For both single- and double-gang installation on existing construction. Not to be used for AC circuits.
110 volt. 4.256" high. Non-conductive, smooth plastic construction. For communications, cable TV,
computer wiring. CAT 5 listed. Adjusts to fit 1/4"- to 1"-thick wallboard, paneling, or drywall. Bracket is
its own template for cutout. Specially designed wing flips up when mounting screw is tightened for a
secure mount. UL listed.
Single gang, 2.507" wide BE@.050 Ea 1.42 2.18 3.61
Double gang, 4.185" wide BE@.050 Ea 2.76 2.18 4.94

EMT Conduit and Fittings

Remove EMT conduit and wire. Removed in salvage condition.
1/2" to 2" conduit diameter BE@.030 LF -- 1.31 1.31

Electric metallic tube (EMT) conduit. Welded and galvanized. UL listed. NEC approved. Meets ANSI
specifications. Sold in 10' lengths. Labor assumes installation in exposed frame walls.
1/2" nominal diameter BE@.033 LF 0.30 1.44 1.74
3/4" nominal diameter BE@.035 LF 0.46 1.53 1.99
1" nominal diameter BE@.040 LF 0.79 1.75 2.53
1-1/4" nominal diameter BE@.045 LF 1.25 1.96 3.22
