2018 National Home Improvement Estimator, All Rights Reserved Page 424

EMT to box offset compression connector. Die-cast zinc. Indoor and outdoor use. Concrete-tight.
Connects EMT conduit to a metal outlet box or other enclosure where an offset is required. UL listed.
1/2" conduit BE@.100 Ea 2.74 4.36 7.10
3/4" conduit BE@.100 Ea 3.73 4.36 8.09

EMT to flex combination coupling, compression to screw-in. Die-cast zinc. Indoor or outdoor use.
Joins EMT conduit to flexible metal conduit. UL listed.
1/2" BE@.050 Ea 2.47 2.18 4.66
3/4" BE@.060 Ea 3.01 2.62 5.63
1" BE@.150 Ea 3.85 6.55 10.39

EMT to non-metallic sheathed cable coupling.
1/2" BE@.100 Ea 0.71 4.36 5.07

EMT 1-hole strap. Zinc plated steel. Snap-on style. Indoor and outdoor use. Supports EMT conduit.
1/2" BE@.050 Ea 0.24 2.18 2.42
3/4" BE@.050 Ea 0.35 2.18 2.54
1" BE@.080 Ea 0.44 3.49 3.94
1-1/4" BE@.100 Ea 0.61 4.36 4.97
1-1/2" BE@.100 Ea 0.72 4.36 5.08
2" BE@.100 Ea 0.76 4.36 5.12

EMT 2-hole strap. Zinc plated steel. Indoor or outdoor use. Supports EMT conduit where greater
load-bearing capacity is required. UL listed.
1/2" BE@.030 Ea 0.26 1.31 1.57
3/4" BE@.040 Ea 0.36 1.75 2.11
1-1/4" BE@.050 Ea 0.68 2.18 2.86
1-1/2" BE@.050 Ea 0.81 2.18 2.99
2" BE@.100 Ea 1.24 4.36 5.61

Metal Conduit Boxes

Install conduit box in confined area. Installed in an area such as an attic, crawlspace or inserted in
a wall.
Junction, switch or outlet box BE@.420 Ea -- 18.33 18.33

Drawn handy box. 4" x 2", 1-7/8" deep. 13-cubic-inch capacity. Used to mount switches or
receptacles. Bracket for wood or metal studs. Drawn construction. UL listed. KO (knockout).
(3) 1/2" side KOs,
(3) 1/2" bottom KOs BE@.200 Ea 1.99 8.73 10.72
(3) 1/2" side KOs,
(2) 1/2" end KOs, (3) 1/2" bottom KOs BE@.200 Ea 2.60 8.73 11.32

Welded handy box, RACO®. 2-1/8" deep. 16.5-cubic-inch capacity. Used to mount switches or
receptacles. Bracket for wood or metal studs. UL listed. KO (knockout).
4" x 2", (2) 1/2" end KOs,
(3) 1/2" bottom KOs BE@.200 Ea 2.29 8.73 11.02
4" x 2", (3) 1/2" side KOs,
(2) 1/2" end KOs, (3) 1/2" bottom KOs BE@.200 Ea 2.99 8.73 11.72

Handy box cover, RACO®. Covers also may be used as single gang wall plates. Includes captive
screws.
20-amp receptacle BE@.030 Ea 1.41 1.31 2.72
Duplex receptacle BE@.030 Ea 0.68 1.31 1.99
Toggle switch BE@.030 Ea 0.68 1.31 1.99
