2018 National Home Improvement Estimator, All Rights Reserved Page 425

Welded square box, RACO®. Used to mount switches and receptacles. 42-cubic-inch wiring
capacity. Welded construction. UL listed. KO (knockout).
(2) 1/2" side KOs, (7) top KOs,
(1) 1/2", (2) 3/4" bottom KOs BE@.300 Ea 6.79 13.09 19.88
(2) 1/2" and (10) TKO side KOs,
(2) 3/4" and (1) 1/2" TKO bottom KOs BE@.300 Ea 4.63 13.09 17.72
(4) 3/4", (4) 1" side KOs,
(3) 1/2", (2) 3/4" bottom KOs BE@.300 Ea 5.25 13.09 18.34

Square surface box cover. 30- to 50-amp receptacle. Steel. Raised 1/2".
2.156" diameter BE@.060 Ea 6.09 2.62 8.71

Multi-gang switch box with conduit KOs, RACO®. Steel. 2-1/2" deep. Combination 1/2" and 3/4"
KOs. UL listed. KO (knockout).
3 gang, 5-19/32" wide,
(6) top, (2) bottom, (3) back KOs BE@.200 Ea 9.25 8.73 17.98
4 gang, 7-19/32" wide,
(8) top, (2) bottom, (4) back KOs BE@.200 Ea 9.25 8.73 17.98

Drawn 2-device switch box, RACO®. 4" x 4". Used to mount switches or receptacles.
30.3-cubic-inch wiring capacity. Bracket for wood or metal studs. Drawn construction. KO (knockout).
1/2" side KOs,
(5) 1/2" bottom KOs BE@.200 Ea 5.84 8.73 14.57
(2) 1/2", (1) 3/4" side KOs,
(3) 1/2", (2) 3/4" bottom KOs BE@.200 Ea 5.69 8.73 14.41
(2) 3/4" side KOs,
(3) 1/2", (2) 3/4" bottom KOs BE@.200 Ea 6.65 8.73 15.37

Finished box cover. Baked Cadilite finished steel. 4" square. 1/2" deep. Fully depressed corners for
easier mounting. UL listed.
1 GFCI receptacle BE@.050 Ea 1.47 2.18 3.66
1 single receptacle BE@.050 Ea 1.61 2.18 3.79
1 duplex receptacle BE@.050 Ea 1.31 2.18 3.50
2 duplex receptacles BE@.050 Ea 1.35 2.18 3.54
1 toggle switch BE@.050 Ea 1.59 2.18 3.77
2 toggle switches BE@.050 Ea 1.59 2.18 3.77
Toggle and duplex BE@.050 Ea 1.53 2.18 3.71

Ceiling fan box. Steel. UL listed for installation of ceiling fans up to 35 pounds. Fixture supports up to
50 pounds. Affixes to joist or cross brace. 4 side cable knockouts, (2) 1/2" side conduit knockouts, 1/2"
bottom conduit knockout.
4", includes fan-mounting screws
with lock washers BE@.200 Ea 5.28 8.73 14.01

Ceiling fan pancake box. 6-cubic-inch capacity. Steel. Includes fan-mounting screws with lock
washers. UL listed for installation of ceiling fans up to 35 pounds. Fixture supports up to 50 pounds.
Affixes to joist or cross brace. Includes non-metallic connector. KO (knockout).
4", 1/2" deep, (4) 1/2" bottom KOs BE@.200 Ea 3.16 8.73 11.89

R-3 drawn octagon box, RACO®. Used to support ceiling light fixture. Sides have (4) 1/2" knockouts,
bottom has 1/2" knockout. 50-pound maximum light fixture support. Not designed for ceiling fan support.
UL listed.
11.8 cubic inch capacity BE@.200 Ea 1.96 8.73 10.69
