Page 537 - 2018 National Home Improvement

2018 National Home Improvement Estimator, All Rights Reserved Page 427

Flex squeeze connector. Die-cast zinc. Indoor use only. In a dry location, use to connect flexible
metallic conduit to a metal enclosure such as a steel outlet box or load center. 3/8" size fits 1/2"
knockout. UL listed.
3/8" conduit BE@.050 Ea 0.54 2.18 2.72
1/2" conduit BE@.050 Ea 0.69 2.18 2.87
3/4" conduit BE@.060 Ea 1.05 2.62 3.67
1" conduit BE@.080 Ea 1.49 3.49 4.99

Electrical non-metallic flex tubing (ENT) conduit, Carlon®. Flex-Plus® Blue™ ENT. No special
tools required. Highly flexible. Cuts easily and cleanly. For use with 90-degree Celsius conductors.
Corrugated design for easy wire pulling and pushing. NER-290 recognized by BOCA, ICC and SBCCI.
UL listed. By nominal trade size.
1/2", per foot BE@.021 LF 0.44 0.92 1.36
1/2", 10' coil BE@.021 LF 0.40 0.92 1.32
1/2", 200' coil BE@.021 LF 0.25 0.92 1.17
3/4", per foot BE@.022 LF 0.53 0.96 1.49
3/4", 10' coil BE@.022 LF 0.49 0.96 1.45
3/4", 100' coil BE@.025 LF 0.40 1.09 1.50
1", 10' coil BE@.040 LF 0.51 1.75 2.25

Carflex® non-metallic liquid-tight flexible conduit, Carlon®. Non-conductive, non-corrosive,
crush-, abrasion- and stain-resistant. Used to connect air conditioning and heating equipment for
outdoor wiring and controls.
1/2", per foot BE@.020 LF 0.77 0.87 1.64
1/2", 100' coil BE@.020 LF 0.42 0.87 1.30
3/4", per foot BE@.020 LF 0.85 0.87 1.72
3/4", 100' coil BE@.020 LF 0.56 0.87 1.43
1", per foot BE@.025 LF 1.44 1.09 2.54
1", 100' coil BE@.025 LF 1.33 1.09 2.42
2", per foot BE@.030 LF 3.16 1.31 4.47

Carflex® conduit fitting, Carlon®. Requires no disassembly of components for installation. Locknut,
O-rings and foam washer assembled onto fitting. Withstands temperatures up to 140 degrees F. UL
listed.
1/2" 90-degree ell BE@.100 Ea 3.01 4.36 7.37
3/4" 90-degree ell BE@.100 Ea 3.39 4.36 7.76
1" 90-degree ell BE@.150 Ea 4.59 6.55 11.13
1/2" straight coupling BE@.100 Ea 2.25 4.36 6.62
3/4" straight coupling BE@.100 Ea 2.56 4.36 6.92
1" straight coupling BE@.150 Ea 3.92 6.55 10.46

Weatherproof Conduit Boxes and Fittings

1-gang rectangular steel weatherproof conduit box, Red Dot®. Includes mounting lugs, hole plugs
and screws. UL listed. Silver.
1/2" hole, 3 holes BE@.300 Ea 3.81 13.09 16.90
1/2" hole, 4 holes BE@.300 Ea 5.15 13.09 18.24
1/2" hole, 5 holes BE@.300 Ea 6.34 13.09 19.43
1/2" hole, 5 holes, 2 side holes BE@.300 Ea 6.86 13.09 19.95
3/4" hole, 3 holes BE@.300 Ea 5.77 13.09 18.86
3/4" hole, 4 holes BE@.300 Ea 6.86 13.09 19.95
3/4" hole, 5 holes BE@.300 Ea 7.31 13.09 20.40

2-gang steel weatherproof conduit box, Red Dot®. Includes mounting lugs, hole plugs and screws.
UL listed. Silver.
1/2" hole, 3 holes BE@.300 Ea 9.19 13.09 22.28
