Cable two-piece clamp connector. Zinc-plated steel. Butterfly style, does not require a locknut. For
indoor use only in a dry location, Secures 14 to 10 gauge non-metallic sheathed cable to a steel outlet
box or other metal enclosure. 3/8" size fits 1/2" knockout. UL listed.
3/8" BE@.050 Ea 0.40 2.18 2.59
3/4" to 1" BE@.050 Ea 0.86 2.18 3.04
1-1/4" BE@.050 Ea 1.47 2.18 3.66
1-1/2" BE@.050 Ea 1.78 2.18 3.96

Stud nail plate. Steel. Installed at each stud to protect cable bored through framing, as defined in NEC
Article 300-4.
1-1/2" x 2-1/2", each BE@.050 Ea 0.24 2.18 2.42
1-1/2" x 2-1/2", pack of 50 BE@2.50 Ea 12.18 109.10 121.28
1-1/2" x 5", each BE@.100 Ea 0.43 4.36 4.80

Type UF Non-Metallic Cable

UF-B sheathed underground cable. Gray. With ground. Used to supply power to landscape lighting,
pumps and other loads connected from the main building. Designed for burial in a trench. Add the cost
of excavation and backfill.
14 gauge, 2 conductor, per foot BE@.010 LF 1.05 0.44 1.49
14 gauge, 2 conductor, 25' coil BE@.010 LF 0.49 0.44 0.93
14 gauge, 2 conductor, 100' coil BE@.010 LF 0.38 0.44 0.82
14 gauge, 3 conductor, per foot BE@.010 LF 1.19 0.44 1.63
14 gauge, 3 conductor, 25' coil BE@.010 LF 0.90 0.44 1.33
14 gauge, 3 conductor, 50' coil BE@.010 LF 0.74 0.44 1.17
12 gauge, 2 conductor, per foot BE@.010 LF 1.10 0.44 1.54
12 gauge, 2 conductor, 25' coil BE@.010 LF 0.78 0.44 1.21
12 gauge, 2 conductor, 50' coil BE@.010 LF 0.74 0.44 1.17
12 gauge, 2 conductor, 100' coil BE@.010 LF 0.60 0.44 1.03
12 gauge, 3 conductor, per foot BE@.010 LF 1.81 0.44 2.24
12 gauge, 3 conductor, 100' coil BE@.010 LF 0.71 0.44 1.14
10 gauge, 2 conductor, per foot BE@.010 LF 1.20 0.44 1.64
10 gauge, 3 conductor, per foot BE@.010 LF 2.43 0.44 2.87

UF non-metallic cable compression connector. Compression-type connector for underground feeder
cable. Fits smaller UF cables as well as standard sizes. Box knockout size is the same as the nominal
conduit size. UL listed.
1/2", 14 to 12 gauge, 2 conductor BE@.050 Ea 4.49 2.18 6.68
3/4", 14 to 12 gauge, 3 conductor BE@.060 Ea 4.23 2.62 6.85

AC-90® steel armored flexible cable, American Flexible Conduit. Galvanized steel. 16 gauge
integral bond wire-to-armor grounding path. Sometimes referred to as “BX” cable. Paper wrap conductor
insulation covering. Maximum temperature rating is 90 degrees Celsius (dry). 600 volts. UL listed. By
American Wire Gauge size and number of conductors. Add the cost of fishing cable through enclosed
walls when required.
14 gauge, 3 conductor, 25' coil BE@.020 LF 1.23 0.87 2.11
14 gauge, 4 conductor, per foot BE@.021 LF 2.43 0.92 3.35
14 gauge, 4 conductor, 250' coil BE@.021 LF 1.17 0.92 2.09
12 gauge, 3 conductor, 50' coil BE@.021 LF 1.23 0.92 2.15
12 gauge, 3 conductor, 100' coil BE@.021 LF 1.08 0.92 2.00
12 gauge, 4 conductor, per foot BE@.023 LF 1.81 1.00 2.81
12 gauge, 4 conductor, 250' reel BE@.023 LF 1.07 1.00 2.07
10 gauge, 3 conductor, 125' coil BE@.027 LF 1.31 1.18 2.49
