2018 National Home Improvement Estimator, All Rights Reserved Page 420

PVC Conduit and Fittings

PVC conduit, Schedule 40. For above- or below-ground applications subject to physical abuse. Also
for use encased in concrete or for direct burial. Sunlight resistant. For use with conductors rated to 90
degrees Celsius. Sold in 10' lengths. Nominal sizes, by outside diameter (OD), inside diameter (ID) and
wall thickness:
Nominal 1/2" measures 0.840" OD, 0.622" ID and 0.109" in wall thickness.
Nominal 3/4" measures 1.050" OD, 0.820" ID and 0.113" in wall thickness.
Nominal 1" measures 1.315" OD, 1.049" ID and 0.133" in wall thickness.
Nominal 1-1/4" measures 1.660" OD, 1.380" ID and 0.140" in wall thickness.
Nominal 1-1/2" measures 1.900" OD, 1.610" ID and 0.145" in wall thickness.
Nominal 2" measures 2.375" OD, 2.067" ID and 0.154" in wall thickness.
Nominal 2-1/2" measures 2.875" OD, 2.469" ID and 0.203" in wall thickness.
1/2" nominal diameter BE@.031 LF 0.23 1.35 1.59
3/4" nominal diameter BE@.032 LF 0.28 1.40 1.68
1" nominal diameter BE@.033 LF 0.42 1.44 1.86
1-1/4" nominal diameter BE@.034 LF 0.62 1.48 2.10
1-1/2" nominal diameter BE@.035 LF 0.71 1.53 2.23
2" nominal diameter BE@.035 LF 0.86 1.53 2.39
2-1/2" nominal diameter BE@.039 LF 1.69 1.70 3.39

PVC conduit, Schedule 80. For above- or below-ground applications subject to physical abuse. Also
for use encased in concrete or for direct burial. Sunlight resistant. For use with conductors rated to 90
degrees Celsius. Meets specifications of Underwriters Laboratories 651 and the National Electrical
Manufacturers Association TC 2.
1/2" nominal diameter BE@.034 LF 0.41 1.48 1.90
3/4" nominal diameter BE@.035 LF 0.53 1.53 2.05
1" nominal diameter BE@.036 LF 0.73 1.57 2.30
1-1/4" nominal diameter BE@.034 LF 1.06 1.48 2.54
1-1/2" nominal diameter BE@.035 LF 1.29 1.53 2.82
2" nominal diameter BE@.040 LF 1.50 1.75 3.25
2-1/2" nominal diameter BE@.042 LF 2.37 1.83 4.21

Snap Strap PVC conduit clamp, Carlon®. For installation of polyvinyl chloride conduit. Can be used
with rigid steel. Indoor use only. All plastic clamp allows conduit to expand and contract with
temperature changes, eliminating bowing.
Single mount, 1/2" BE@.050 Ea 0.65 2.18 2.83
Single mount, 3/4" BE@.050 Ea 0.72 2.18 2.90
Single mount, 1" BE@.050 Ea 0.82 2.18 3.00
Double mount, 1-1/4" BE@.050 Ea 0.90 2.18 3.08
Double mount, 2" BE@.050 Ea 1.13 2.18 3.31

Non-metallic reducer bushing, Carlon®. Rigid Schedule 40 PVC conduit reducer. Socket ends.
Male x female. UL listed.
3/4" x 1/2" BE@.030 Ea 1.01 1.31 2.32
1" x 1/2" BE@.030 Ea 1.33 1.31 2.64
1" x 3/4" BE@.040 Ea 2.14 1.75 3.89
1-1/4" x 3/4" BE@.050 Ea 2.11 2.18 4.29
1-1/4" x 1" BE@.050 Ea 2.37 2.18 4.56
1-1/2" x 1" BE@.050 Ea 2.37 2.18 4.56
1-1/2" x 1-1/4" BE@.050 Ea 2.81 2.18 4.99
2" x 1-1/4" BE@.060 Ea 3.14 2.62 5.76
2" x 1-1/2" BE@.060 Ea 3.29 2.62 5.91
2-1/2" x 2" BE@.060 Ea 8.23 2.62 10.85
