2018 National Home Improvement Estimator, All Rights Reserved Page 439

No. QO612L100SCP, 100 amp,
6 spaces, 12 circuits,
main wire #8-1 Al and Cu BE@.800 Ea 25.45 34.91 60.36
No. QO816L100DS, 100 amp,
8 spaces, 16 circuits,
main wire #8-1 Al and Cu BE@.900 Ea 46.16 39.28 85.44
No. QO816L100SCP, 100 amp,
8 spaces, 16 circuits
main wire #8-1 Al and Cu BE@.900 Ea 40.30 39.28 79.58

QO® outdoor main lug load center, QOM1 frame size, Square D®. Single-phase, 3-wire,
120/240-volt AC. Main wire #6-2/0 aluminum or copper. 65,000 RMS symmetrical amp short circuit
current rating. Metallic enclosure. Convertible mains. Factory-installed main lug. QOM1 main frame
size. Convertible to main circuit breaker. Straight-in mains. Includes rainproof cover. Order ground bar kit
separately. Order QO, QOT, QO-GFI, QO-EPD, QO-AFI OR QO-APL branch circuit breakers
separately. Install Square D QO type circuit breakers only. 10-year limited warranty. UL Listed.
No. QO11224L125GRB, 125 amp,
12 spaces, 24 circuits BE@.800 Ea 98.68 34.91 133.59

QO® miniature circuit breaker, Square D®. Single pole. Square D QO miniature circuit breakers are
plug-in products for use in QO load centers and NQOD panelboards. 120/240-volts AC. 10,000-amp
interrupting rating (AIR) RMS symmetrical with VISI-TRIP® indicator. Class 730, 731 and 733. 1 space
required. Use in Square D QO load centers only. UL listed.
15 amp, 1 pole BE@.150 Ea 7.40 6.55 13.95
20 amp, 1 pole BE@.150 Ea 7.40 6.55 13.95
25 amp, 1 pole BE@.150 Ea 7.40 6.55 13.95
30 amp, 1 pole BE@.150 Ea 7.40 6.55 13.95
40 amp, 1 pole BE@.150 Ea 7.74 6.55 14.28
50 amp, 1 pole BE@.150 Ea 7.74 6.55 14.28
15 amp, 2 pole BE@.150 Ea 16.97 6.55 23.51
20 amp, 2 pole BE@.150 Ea 16.97 6.55 23.51
25 amp, 2 pole BE@.150 Ea 16.97 6.55 23.51
25 amp, 2 pole BE@.150 Ea 16.97 6.55 23.51
30 amp, 2 pole BE@.150 Ea 16.97 6.55 23.51
40 amp, 2 pole BE@.150 Ea 16.97 6.55 23.51
50 amp, 2 pole BE@.150 Ea 16.97 6.55 23.51

Replacement tandem circuit breaker, QO®, Square D®. 1 pole. 120-volts AC. 10,000 AIR. For use
in Square D QO load centers manufactured before 1967. UL listed.
15 and 15 amp BE@.150 Ea 44.54 6.55 51.09
20 and 20 amp BE@.150 Ea 44.54 6.55 51.09

Tandem circuit breaker, Square D®. 1 pole. 120-volts AC. 10,000 AIR. HACR type. Visi-Trip®
indicator. Requires handle tie No. QOTHT for common switching. For use in Square D QO load centers
manufactured after 1967. UL listed as CTL.
15 and 15 amp BE@.150 Ea 19.59 6.55 26.14
20 and 20 amp BE@.150 Ea 19.59 6.55 26.14
