2018 National Home Improvement Estimator, All Rights Reserved Page 440

Ground-fault interrupter plug-on circuit breaker, QO-GFI Qwik-Gard®, Square D®.
QWIK-GARD® circuit breakers provide overload and short circuit protection, combined with Class A
ground-fault protection. Class A denotes a ground-fault circuit interrupter that will trip when a
ground-fault current is 6 milliamperes or greater, for people protection. Do not connect to more than 250'
of load conductor for the total one-way run to prevent nuisance tripping. Class 685, 690, 730, 912 and
950. 10,000 AIR. HACR type. Visi-Trip® indicator. 1 poles are 120 volt and 2 poles are 120/240 volt.
2-pole breakers have common trip, 120-volts AC. 2 spaces required for 2-pole breakers. UL listed.
20 amp, 1 pole BE@.150 Ea 94.64 6.55 101.18
20 amp, 2 pole BE@.150 Ea 101.00 6.55 107.55
30 amp, 2 pole BE@.150 Ea 109.08 6.55 115.63
50 amp, 2 pole BE@.150 Ea 191.90 6.55 198.45
60 amp, 2 pole BE@.150 Ea 191.90 6.55 198.45

QO® load center ground bar kit, Square D®. Sold separately from the QO® load centers. Indoor,
single phase, main lug, class 736 and 1130. Aluminum. UL listed.
No. PK3GTA, 3 terminal BE@.200 Ea 4.21 8.73 12.94
No. PK4GTA, 4 terminal BE@.200 Ea 4.75 8.73 13.48
No. PK7GTA, 7 terminal BE@.200 Ea 5.28 8.73 14.01
No. PK9GTA, 9 terminal BE@.200 Ea 5.92 8.73 14.65
No. PK12GTACP, 12 terminal BE@.200 Ea 5.92 8.73 14.65
No. PK15GTA, 15 terminal BE@.200 Ea 7.12 8.73 15.85

Recessed Lighting

Recessed low-voltage baffle light kit, remodel, Commercial Electric. Not for direct contact with
insulation. 4" black baffle trim. Uses (1) MR16 bulb, 50 watt (included). Minimizes glare in general,
accent and task lighting. Pre-wired housing. Thermally protected. UL listed for damp locations. For
suspended ceilings. Installation instructions and template enclosed. Compatible with standard wall
dimmer.
4", with black baffle trim BE@1.00 Ea 45.45 43.64 89.09

Recessed low-voltage slot aperture light kit, remodel, Commercial Electric. Not for direct contact
with insulation. 4" white slot aperture trim. Uses (1) MR16 bulb, 50 watt (included). Pre-wired housing.
Thermally protected. UL listed for damp locations. For suspended ceilings. Installation instructions and
template enclosed. Compatible with standard wall dimmer.
4", white slot aperture trim BE@1.00 Ea 51.51 43.64 95.15

Mini can recessed eyeball trim light kit, Commercial Electric. 5" mini non-IC housing. 5" white
eyeball trim. For new or remodel construction. Not for direct contact with insulation. For suspended
ceilings or joist support (hanger bars sold separately). Pre-wired housing. Thermally protected. UL listed
for damp locations. Compatible with standard wall dimmer. 75-watt maximum, PAR-30 bulb (not
included).
5", white BE@1.00 Ea 12.12 43.64 55.76
5", white LED BE@1.00 Ea 32.32 43.64 75.96

Mini can recessed open light kit, Commercial Electric. 5" mini non-IC housing. 5" white open trim.
For new or remodel construction. Not for direct contact with insulation. For suspended ceilings or joist
support (hanger bars sold separately). Pre-wired housing. Thermally protected. UL listed for damp
locations. Compatible with standard wall dimmer.
5", white BE@1.00 Ea 12.12 43.64 55.76

Recessed light kit. For use in an insulated ceiling. Kit includes housing and trim. For new
construction.
6", white trim BE@.700 Ea 22.93 30.55 53.48
