2018 National Home Improvement Estimator, All Rights Reserved Page 438

Combination service entrance device, Square D®. All-in-one main circuit breaker panel.
Surface-mount. Includes ring-type utility meter socket, service disconnect, and integral load center.
HOM load center with surface outdoor enclosure. Single-phase, 3-wire. 120/240-volt AC, 10,000 amp
short circuit current rating. NEMA Type 3R enclosure. Overhead or underground service feed. Left meter
location. Hub style A. Suitable only for use as service equipment. UL listed. Meets EUSERC standards.
10-year limited warranty.
No. SC1624M100S, 100 amp,
16 spaces, 24 circuits BE@1.30 Ea 62.01 56.73 118.74
No. SC1624M125S2, 125 amp,
16 spaces, 24 circuits BE@1.30 Ea 111.10 56.73 167.83
No. SC2040M200C, 200 amp,
20 spaces, 40 circuits BE@1.30 Ea 141.40 56.73 198.13

Combination service entrance device, Square D®. All-in-one main circuit breaker panel. Surface
mount. Includes ring-type utility meter socket, service disconnect, and integral load center. HOM load
center with surface outdoor enclosure. Single-phase, 3-wire, 120/240-volt AC, 22,000 amp short circuit
current rating. NEMA Type 3R enclosure. Overhead or underground service feed. Left meter location.
Hub style A. Suitable only for use as service equipment. UL listed. Meets EUSERC standards. 10-year
limited warranty.
No. SC2040M200S, 200 amp,
20 spaces, 40 circuit BE@1.30 Ea 134.33 56.73 191.06
No. SC3040M200SS, 200 amp,
30 spaces, 40 circuit BE@1.30 Ea 165.64 56.73 222.37
No. SC40M200S, 200 amp,
40 spaces, 40 circuit BE@1.30 Ea 139.38 56.73 196.11

Bolt-on A Type universal hub, Square D®. Bolt-on closing plate for A or A-L hub opening. Series A
style. For Class 4131 meter socket. Class 4119 service entrance device. Aluminum. UL listed.
Threaded for rigid conduit.
1" conduit BE@.050 Ea 8.88 2.18 11.06
1-1/4" conduit BE@.050 Ea 8.72 2.18 10.90
1-1/2" conduit BE@.050 Ea 8.72 2.18 10.90
2" conduit BE@.050 Ea 8.72 2.18 10.90

Main circuit breaker, Class 1130 QO® main lugs, rainproof, Square D®. 2-pole, 22,000 AC rated.
For convertible load centers only. Load center main rating. KCM is thousand circular mils.
100 amp, AWG #4 to 2/0 BE@.150 Ea 56.16 6.55 62.70
125 amp, AWG #4 to 2/0 BE@.150 Ea 60.40 6.55 66.94
200 amp, AWG #4 to 300 KCM BE@.150 Ea 82.72 6.55 89.27

QO® Indoor main lug load center, Square D®. Surface-mount. Class 736, 1130. Single-phase,
3-wire, 120/240-volt AC. Fixed mains. Factory-installed main lugs. 10,000 RMS amp short circuit
current rating. Shielded copper bus. Straight-in mains. Rotates for top or bottom feed. Cover included.
Ground bar kit sold separately. Uses QO, QOT, QO-EPD, QO-GFI or QO-PL branch circuit breakers
separately. UL listed. 10-year limited warranty.
No. QO2L30SCP, 30 amp,
2 spaces, 2 circuits,
main wire #12-10 Al, #14-10 Cu BE@.450 Ea 14.54 19.64 34.18
No. QO24L70SCP, 70 amp,
2 spaces, 4 circuits,
main wire #12-3 Al, #14-4 Cu BE@.500 Ea 18.48 21.82 40.30
No. QO612L100DS, 100 amp,
6 spaces, 12 circuits,
main wire #8-1 Al and Cu BE@.800 Ea 34.54 34.91 69.45
