Page 550 - 2018 National Home Improvement

2018 National Home Improvement Estimator, All Rights Reserved Page 435

Commercial-grade duplex receptacle, Leviton. Side wired. 125 volts. Ground out. Large head
triple-drive terminal screws, backed out and staked. Terminals and back-wiring clamps. Accepts 10
gauge copper or copper-clad wire. Rust-resistant mounting strap. Washer-type break-off plaster ears.
Captive-mounting screws. 15-amp, NEMA 5-15R. 20-amp NEMA 2-20R. UL listed.
15 amps BE@.200 Ea 2.40 8.73 11.13
20 amps BE@.200 Ea 3.61 8.73 12.33

CO/ALR duplex receptacle, Leviton. Residential grade. 125 volts. Side-wired grounding. Fits shallow
receptacle. Large head terminal screws accept up to 12 gauge copper or copper-clad wire. Quickwire
push-in terminals accept 14 gauge solid copper wire only. Rust-resistant steel mounting strap. Break-off
plaster ears. Captive mounting screws. Break-off tabs allow easy two-circuit conversion. 5-15R. UL
listed.
15 amps, ivory BE@.200 Ea 3.17 8.73 11.90
15 amps, white BE@.200 Ea 3.17 8.73 11.90

GFCI hospital-grade receptacle.
20 amps, ivory BE@.300 Ea 29.29 13.09 42.38
20 amps, red BE@.300 Ea 29.29 13.09 42.38

GFCI receptacle. 15-amp shock guard ground fault circuit interrupter. Side- and back-wired to accept
12 gauge wire. Shallow design allows for easy installation.
15 amps, ivory BE@.300 Ea 26.26 13.09 39.35
15 amps, white BE@.300 Ea 26.26 13.09 39.35

Single receptacle, Leviton. Commercial grade. Large head triple-drive terminal screws, backed out
and staked. Terminals and back-wiring clamps accept 10 gauge copper or copper-clad wire.
Heavy-gauge, rust-resistant steel mounting strap. Convenient washer-type break-off plaster ears for best
flush alignment. Triple-wide power contacts. Captive-mounting screws.
15 amps, 125 volts BE@.200 Ea 4.27 8.73 13.00
20 amps, 125 volts BE@.200 Ea 5.49 8.73 14.22
20 amps, 250 volts BE@.200 Ea 6.72 8.73 15.44

Appliance receptacle, flush mount, Pass & Seymour/Legrand. Straight blade receptacle. Industrial
specification grade. 125/250-volt, 60 Hz, AC only. For copper or aluminum conductors. Easily
identifiable color-coded terminals. Double-wipe copper alloy contacts. Terminals accept up to #4
conductors. Fits single- or 2-gang outlet boxes. Includes mounting hardware. UL listed.
NEMA 14-30R, 30 amps, dryer BE@.350 Ea 9.00 15.27 24.27
NEMA 14-50R, 50 amps, range BE@.400 Ea 9.42 17.46 26.88

Single-gang plastic wall plate, Leviton. Residential grade. Standard size. Resists fading,
discoloration, grease, oils, organic solvents and scratches. Round on edges to prevent injury and wall
damage. Includes matching metal mounting screws. UL listed.
1 duplex receptacle BE@.050 Ea 0.30 2.18 2.49
2 duplex receptacles BE@.100 Ea 1.03 4.36 5.39
1 toggle switch BE@.050 Ea 0.30 2.18 2.49
1 toggle, 1 duplex receptacle BE@.100 Ea 1.05 4.36 5.41
2 toggle switches BE@.100 Ea 1.03 4.36 5.39
Blank BE@.050 Ea 0.63 2.18 2.81

Single-gang Decora® wall plate, Leviton. Smooth face and round edges that resist dust
accumulation. Individual plastic wrapping to protect surfaces. Color-matched mounting screws included.
UL listed.
1 rocker switch BE@.050 Ea 0.63 2.18 2.81
2 rocker switches BE@.100 Ea 1.25 4.36 5.62
1 rocker switch, 1 toggle BE@.100 Ea 1.49 4.36 5.86
