2018 National Home Improvement Estimator, All Rights Reserved Page 433

10 gauge, stranded, per foot BE@.008 LF 0.68 0.35 1.03
10 gauge, stranded, 50' coil BE@.008 LF 0.37 0.35 0.72
10 gauge, stranded, 100' coil BE@.008 LF 0.30 0.35 0.65
10 gauge, stranded, 500' coil BE@.008 LF 0.17 0.35 0.52
8 gauge, stranded, per foot BE@.009 LF 0.72 0.39 1.11
8 gauge, stranded, 500' coil BE@.009 LF 0.29 0.39 0.69
6 gauge, stranded, per foot BE@.010 LF 0.66 0.44 1.09
6 gauge, stranded, 500' coil BE@.010 LF 0.43 0.44 0.87

20 gauge bell wire, Carol® Cable. For alarms, thermostat controls, touch plate systems, burglar
alarms, doorbells and other low voltage installations.
2 conductor, 500' coil BE@.006 LF 0.08 0.26 0.34

18 gauge thermostat cable, Carol® Cable. For thermostat control, heating and air conditioning,
touch plate systems, burglar alarms, intercom systems, doorbells, remote control units, signal
systems, and other low voltage installations. Annealed solid bare copper conductors. PVC insulation
and white jacket. UL listed. Type CL-2.
2 conductor, 50' roll BE@.006 LF 0.21 0.26 0.47
2 conductor, 100' roll BE@.006 LF 0.16 0.26 0.42
5 conductor, 50' roll BE@.006 LF 0.38 0.26 0.65
5 conductor, 100' roll BE@.006 LF 0.26 0.26 0.52

Speaker wire. Clear jacket. Low-noise copper wire.
16 gauge, 50' long BE@.008 LF 0.26 0.35 0.61
16 gauge, 100' long BE@.008 LF 0.21 0.35 0.56
18 gauge, 50' long BE@.008 LF 0.20 0.35 0.55
18 gauge, 100' long BE@.008 LF 0.14 0.35 0.49

Coaxial cable. For RF signal transmission, MATV and CATV, drop cable, and FM broadcast. Solid
bare copper-weld. AWG 18. Cellular polyethylene insulation. 100% aluminum/polyester tape shield with
+55% aluminum braid. 0.308" outside diameter. Capacitance, pF/Ft. 17.3. Vel. propagation: 78%
nominal impedance: 75 ohm. UL listed.
Black, per foot BE@.007 LF 0.27 0.31 0.58
Black, 500' coil BE@.007 LF 0.11 0.31 0.42

Coaxial F connector, RCA. For connecting to RG6 coaxial cable. Lifetime warranty.
Crimp-on BE@.075 Ea 0.64 3.27 3.91
Twist-on BE@.075 Ea 0.85 3.27 4.12

Coaxial cable wall plate. Fits standard electrical outlet box or flush-mount to drywall. Ivory or white.
75 ohm, single BE@.150 Ea 4.08 6.55 10.63
75 ohm, duplex BE@.200 Ea 4.74 8.73 13.46

Category 5E data communication cable, Carol® Cable. UTP; Spec. 4480; Type MPR/CMR.
Suitable for high-speed data/LAN transmission up to 16 Mbps; 10 BASE-T, 4 Mbps token ring, 100
VG-Any LAN, 100 Mbps TP-PMD, 100 BASE-T, and 55/155 Mbps A™. 24 AWG solid bare annealed
copper construction. Flame retardant PVC insulation. Pairing: two twists per foot. Pull-Pac® cartons.
Maximum DC resistance, 9.38 (omega)/100 m at 20°C (68°F). Mutual capacitance, 4.59pF/Ft. at 1 kHz.
Characteristic impedance for 772 kHz, 87-117 (omega). For 1.0-100.0 MHz, 85-115 (omega). SRL for
1.0-20.0 MHz, 23 dB. For 20.0-100.0 MHz, 23-10 log. Skew 10 ns. NVP, 70% speed of light. UL listed.
cPCCFT4 listed. Meets requirements: ANSI/TIA/EIA 568A, ANSI/ICEA S-90-661 and NEMA WC63.1.
Ivory. 1" outside diameter. 24 gauge.
4 conductor, per foot BE@.007 LF 0.22 0.31 0.53
4 conductor, 500' coil BE@.007 LF 0.11 0.31 0.42

Decorator phone wall plate. Ivory or white.
