2018 National Home Improvement Estimator, All Rights Reserved Page 432

Steel service entrance cap. Copper-free die-cast aluminum. Clamp-on style. For overhead wiring
service entrance. Mounts on top of EMT, rigid or IMC conduit. Serves as connecting point for service
entrance wires. UL listed.
1/2" conduit diameter BE@.150 Ea 4.37 6.55 10.92
3/4" conduit diameter BE@.200 Ea 4.90 8.73 13.63
1" conduit diameter BE@.250 Ea 6.58 10.91 17.49
1-1/4" conduit diameter BE@.300 Ea 7.14 13.09 20.23
1-1/2" conduit diameter BE@.300 Ea 9.30 13.09 22.39
2" conduit diameter BE@.500 Ea 12.22 21.82 34.04
2-1/2" conduit diameter BE@.500 Ea 33.53 21.82 55.35

Rigid or IMC service entrance elbow. Copper-free die-cast aluminum. Indoor or outdoor use. Includes
cover and gasket. Use to gain access to interior of raceway for wire pulling, inspection, and
maintenance. UL listed.
Trade size 1/2" BE@.100 Ea 4.79 4.36 9.15
Trade size 3/4" BE@.150 Ea 7.05 6.55 13.60
Trade size 1" BE@.150 Ea 9.56 6.55 16.11
Trade size 1-1/4" BE@.200 Ea 11.92 8.73 20.65
Trade size 1-1/2" BE@.200 Ea 16.56 8.73 25.29
Trade size 2" BE@.250 Ea 23.13 10.91 34.04

Service entrance roof flashing. Prevents leaks where conduit penetrates the roof surface. Slips over
the conduit mast and mounts on the roof. Made of galvanized steel with neoprene seal.
2" conduit diameter BE@.250 Ea 7.79 10.91 18.70
2-1/2" conduit diameter BE@.250 Ea 9.31 10.91 20.22

Service entrance conduit sill plate. Copper-free die-cast aluminum. Helps seal the hole where
service entrance cable enters the home.
1/2" to 3/4", 2 screws BE@.100 Ea 1.77 4.36 6.13
1", 2 screws BE@.100 Ea 2.36 4.36 6.73
1-1/4", 4 screws BE@.200 Ea 3.14 8.73 11.87
1-1/2", 4 screws BE@.200 Ea 3.84 8.73 12.57
2", 4 screws BE@.200 Ea 5.92 8.73 14.65

Ground rod clamp. Bronze. Connects the grounding wire to the ground rod. Approved for direct burial.
UL listed.
1/2" rod BE@.100 Ea 2.31 4.36 6.68
5/8" rod BE@.100 Ea 2.31 4.36 6.68
3/4" rod BE@.100 Ea 2.90 4.36 7.26
1-1/4" to 2", 8 to 4 gauge wire BE@.100 Ea 3.80 4.36 8.16

Wire and Fittings

Type THHN copper building wire. Labor is based on wire pulled in conduit.
14 gauge, solid, per foot BE@.006 LF 0.32 0.26 0.59
14 gauge, solid, 50' coil BE@.006 LF 0.20 0.26 0.46
14 gauge, solid, 100' coil BE@.006 LF 0.22 0.26 0.48
14 gauge, solid, 500' coil BE@.006 LF 0.07 0.26 0.33
14 gauge, stranded, per foot BE@.006 LF 0.42 0.26 0.69
14 gauge, stranded, 500' coil BE@.006 LF 0.06 0.26 0.32
12 gauge, solid, per foot BE@.007 LF 0.56 0.31 0.86
12 gauge, solid, 50' coil BE@.007 LF 0.24 0.31 0.55
12 gauge, solid, 100' coil BE@.007 LF 0.22 0.31 0.53
12 gauge, solid, 500' coil BE@.007 LF 0.10 0.31 0.41
12 gauge, stranded, per foot BE@.007 LF 0.52 0.31 0.82
12 gauge, stranded, 50' coil BE@.007 LF 0.27 0.31 0.58
