2018 National Home Improvement Estimator, All Rights Reserved Page 49

Concrete slabs, walks and driveways. Typical costs for reinforced concrete slabs-on-grade including
fine grading, slab base, forms, vapor barrier, wire mesh, 3,000 PSI concrete, finishing and curing. For
thickened edge slabs, add the area of the thickened edge. Use 500 square feet as the minimum job
size.
2" thick B5@.067 SF 2.11 2.67 4.78
3" thick B5@.068 SF 2.48 2.71 5.19
4" thick B5@.069 SF 2.86 2.75 5.61
5" thick B5@.070 SF 3.23 2.79 6.02
6" thick B5@.071 SF 3.61 2.83 6.44

Slab Base. Aggregate base for slabs. No waste included. Labor costs are for spreading aggregate from
piles only. Add for fine grading, using hand tools.
Crushed stone base 1.4 tons equal one cubic yard
Using crushed stone, per CY --@.000 CY 38.58 -- 38.58
1" base ( .309 CY per CSF) BL@.001 SF 0.12 0.03 0.15
2" base ( .617 CY per CSF) BL@.003 SF 0.24 0.10 0.34
3" base ( .926 CY per CSF) BL@.004 SF 0.35 0.13 0.48
4" base (1.23 CY per CSF) BL@.006 SF 0.47 0.20 0.67
5" base (1.54 CY per CSF) BL@.007 SF 0.60 0.23 0.82
6" base (1.85 CY per CSF) BL@.008 SF 0.72 0.26 0.98
Sand fill base 1.40 tons equal one cubic yard
Using sand, per CY --@.000 CY 17.98 -- 17.98
1" fill ( .309 CY per CSF) BL@.001 SF 0.05 0.03 0.08
2" fill ( .617 CY per CSF) BL@.002 SF 0.11 0.07 0.18
3" fill ( .926 CY per CSF) BL@.003 SF 0.16 0.10 0.26
4" fill (1.23 CY per CSF) BL@.004 SF 0.22 0.13 0.35
5" fill (1.54 CY per CSF) BL@.006 SF 0.27 0.20 0.47
6" fill (1.85 CY per CSF) BL@.007 SF 0.33 0.23 0.56
Add for fine grading for slab on grade BL@.008 SF -- 0.26 0.26

Concrete finishing.
Slab finishes
Broom finish B6@.012 SF -- 0.43 0.43
Float finish B6@.010 SF -- 0.35 0.35
Trowel finishing
Steel, machine work B6@.015 SF -- 0.53 0.53
Steel, hand work B6@.018 SF -- 0.64 0.64
Finish treads and risers
No abrasives, no plastering, per LF of tread B6@.042 LF -- 1.49 1.49
With abrasives, plastered, per LF of tread B6@.063 LF 0.73 2.23 2.96
Scoring concrete surface, hand work B6@.005 LF -- 0.18 0.18
Sweep, scrub and wash down B6@.006 SF 0.04 0.21 0.25
Liquid curing and sealing compound, spray-on, acrylic concrete cure and seal,
400 SF per gallon B6@.003 SF 0.21 0.11 0.32
Exposed aggregate (washed, including finishing),
no disposal of slurry B6@.017 SF 0.35 0.60 0.96
Non-metallic color and concrete hardener, troweled on, 2 applications, red, gray or black,
60 pounds per 100 SF B6@.021 SF 0.53 0.74 1.27
100 pounds per 100 SF B6@.025 SF 0.87 0.89 1.75
